Solar C Channel
Solar Strut Channel Product details
Name |
|
Thickness |
0.8mm-3.0mm or customer's requirements |
Diameter |
41*21mm,41*41 mm,41*61 mm, 41*82mm |
Standard |
AISI, ASTM, BS, GB, DIN, JIS, etc |
Grade |
Q195, Q235, Q235B, Q345 Q345B etc |
Section Shape |
C Channel |
Application |
Solar Supporting System |
Technique |
Cold Bending/Roll Forming |
Certification |
SGS, ISO9001-2008 |
Surface Treatment |
HDG(hot dipped galvanized ),Pre-galvanized,powder coating (Black,Green,White,Grey,Blue)etc |
Alloy Or Not |
Not alloyed |
Zinc coating |
Normal AVG: 280g/m2(40um), Max.100um |
Pipe End Treatment |
Plain |
Business type |
Manufacturer |
Place of Origin |
Tianjin,China (Mainland) |
Payment terms |
L/C,T/T,D/P,O/A |
No. |
Size |
Thickness |
Type |
SurfaceTreatment |
||
mm |
inch |
mm |
Gauge |
|||
A |
21x10 |
13/16x13/32" |
1.0, 1.5,2.0,2.5,2.75,3.0 |
19,16,14,12 |
Slotted, Solid |
HDG,PG,PC |
B |
21x21 |
13/16x13/16" |
1.0, 1.5,2.0,2.5,2.75,3.0 |
19,16,14,12 |
Slotted, Solid |
HDG,PG,PC |
C |
41x21 |
1-5/8x13/16" |
1.0, 1.5,2.0,2.5,2.75,3.0 |
19,16,14,12 |
Slotted, Solid |
HDG,PG,PC |
D |
41x22 |
1-5/8x7/8" |
1.0, 1.5,2.0,2.5,2.75,3.0 |
19,16,14,12 |
Slotted, Solid |
HDG,PG,PC |
E |
41x25 |
1-5/8x1" |
1.0, 1.5,2.0,2.5,2.75,3.0 |
19,16,14,12 |
Slotted, Solid |
HDG,PG,PC |
F |
41x41 |
1-5/8x1-5/8" |
1.0, 1.5,2.0,2.5,2.75,3.0 |
19,16,14,12 |
Slotted, Solid |
HDG,PG,PC |
G |
41x62 |
1-5/8x2-7/16" |
1.0, 1.5,2.0,2.5,2.75,3.0 |
19,16,14,12 |
Slotted, Solid |
HDG,PG,PC |
H |
41x83 |
1-5/8x3-1/4" |
1.0, 1.5,2.0,2.5,2.75,3.0 |
19,16,14,12 |
Slotted, Solid |
HDG,PG,PC |
Sino Steel Impex Co., Ltd. is a China Solar C Channel Manufacturer, you can be get most careful and thoughtful service! If you want to know more products click here.
