Home > Products > AC Servo Products > 220VAC 2000rpm 4.5KW 16A 3 phase ac automat voltage regular stability ac servo motor
220VAC 2000rpm 4.5KW 16A 3 phase ac automat voltage regular stability ac servo motor
- 1000 Piece / Pieces per Month
- T/T Credit Card
You May Like
-
220v 3000rpm 730 watt 0.5 hp muds083a1a sgmg delta estun set tuator system brushless ac servo motor
-
1000w 220v 2500rpm mecapion harga high torque ac servo system motor sgmg brake ethercat kit
-
1kw 220v 3000rpm teco digit amt806 inova mini flang delta xinj mige ac servo motor
-
220v 1.3kw 2500rpm mige brushless hollow inova brushless ac servo motor reduc for print machine
-
220VAC 1000rpm 2.9KW 12A mini wholesale mige digital servo motor ac set
-
750w 220vac 3000rpm mini panason tus power st automat voltage stabil dorna juki tuator system ac servo motor
Product Details
| Brand Name | PrimoPal | Place of Origin | Shanghai, China | |
| Model Number | PAS180-245020 | Type | Servo Motor | |
| Frequency | 50/60HZ | Efficiency | IE 3 | |
| Certification | CCC, CE, ROHS, UL, VDE | |||
| Phase | Three-phase | Protect Feature | Waterproof |
Product Description
PrimoPal offers a wide selection of high-performance brushless AC servo motors, with power ratings from 200 W to 7.5 KW, output torque from 0.16 Nm to 67 Nm, and maximum speed of up to 6,000 rpm. These motors are designed for outstanding efficiency, reliability and electromagnetic immunity, particularly suitable for positioning tasks in machine automation with demanding requirements for dynamics and stability. The combination of PrimoPal’s servo motors and servo drives delivers an optimal solution for high performance motion applications. Besides, custom motor winding, various feedback devices, permanent magnet brake adders, electromagnetic brake adders and mechanical modifications are also available.
| Operating Temperature | -20°C ~ 50°C |
| Insulation Class | Class B (130°C) |
| Safety Grade | IP65 |
AC servo motor without brake
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
AC servo motor with brake
