Home > Products > Hybrid Stepper Products > NEMA 23 0.8A 70 N.cm 51mm Length Housing Material Metal Sleeve Bearings Reduction Ratio 276 Strong Precision Stepper Gear Motor
NEMA 23 0.8A 70 N.cm 51mm Length Housing Material Metal Sleeve Bearings Reduction Ratio 276 Strong Precision Stepper Gear Motor
US$ 20 - 40
/ Piece
1 Piece(Min. Order)
- Shanghai Ningbo Shenzhen
- T/T Credit Card
You May Like
-
Nema 11 0.6A Current 6N.cm Holding Torque 33mm Length 264 Applicable Ratio Power Hybrid Stepper Planetary Gear Motor
-
Nema 11 0.6A Current 6N.cm Holding Torque 33mm Length 264 Applicable Ratio Power Hybrid Stepper Planetary Gear Motor
-
65mm With Box Spur 264 Planetary Nema 17 Stepper Motor With Gearbox for Robot 0.4a Reducer Laser Cutting Machine Reducer
-
95.4mm Micro 100 Planetary Micro Reducer Nema 17 Gear Stepper Motor With Gearbox for Electr Cnc
-
Nema 11 0.6A Current 10N.cm Holding Torque 50mm Length 100 Applicable Ratio Spur Gear for Hybrid Stepper Planetary Motor
-
Nema 14 0.46A Current 12N.cm Holding Torque 28mm Length 264 Applicable Ratio High Torque Gear Reducer Stepper Motor
Product Details
| Brand Name | PrimoPal | Place of Origin | Shanghai, China | |
| Model Number | PHG57S/PTP56E Series | Type | Hybrid | |
| Phase | 2 | Certification | CE, ISO, ROHS, UL | |
| Current / Phase | Variable, can be custom |
Product Description
PrimoPal's PHG series hybrid stepper gearmotor offers a wide range of gear ratios to fulfill your project needs. The planetary gearhead (transmission series) and spur gearbox have been strictly tested to ensure long life and maximum efficiency. They are low-cost solutions and can perfectly meet your needs of motion or automation control. Besides, high precision gearhead, custom motor winding and gearhead specs are also available.
Contact Us
- Shanghai PrimoPal Precision Motor Co., Ltd.
Product Categories
| AC Induction Motors | AC Servo Products | Brushless DC Products | Gearbox |
| Hybrid Stepper Products | PM DC Motors | PM Stepper Products | Ready to ship products |
| Ungrouped |
