API6D Top Entry Orbit Ball Valve

BQ347F top entry orbit ball valve

Contact: Email: zipopvf@163.com Wechat: zipo2019; QQ: 2191417589; Mobile: 18081659672

Please inform us of the accurate nominal size, pressure class, medium, temperature, material, actuator and other parameters, before consulting or purchasing the product. Thanks!

Orbit ball valve is suitable for petrochemical, LPG storage, oil refinery, natural gas, compressor system, oil and gas transmission pipeline, light industry, textile and other industries.

Product advantages: traditional ball valve, whether floating ball valve or fixed ball valve, the ball always contacts with the valve seat, the switch torque is large, and the sealing surface is easy to be damaged. However, when the orbit ball valve is opened and closed, the ball first deflects, and then rotates, and the ball is separated from the valve seat in the whole process of opening and closing, so the valve seat will not be scratched, and the opening and closing torque is small.

1. No friction between opening and closing. This function completely solves the problem that traditional valve seals are affected by friction between sealing surfaces.

2. Top entry structure. The valve installed on the pipeline can be directly inspected and maintained online. The utility model can effectively reduce the shutdown of the device and the production cost.

3. Single seat design. It eliminates the problem that the medium in the valve cavity affects the usage safety due to abnormal pressure rise.

4. Low torque design. The valve stem with special structure design can be opened and closed easily only with a small hand wheel

5. Wedge seal construction. The valve is sealed by the mechanical force provided by the valve stem to press the ball wedge onto the valve seat. The sealing performance of the valve is not affected by the change of pipeline pressure difference, and the sealing performance is reliably guaranteed under various working conditions.

6. It has a wide range of applications, ranging from small diameter to several millimeters and large diameter to several meters, from high vacuum to high pressure. When the ball rotates 90 degrees, it should be spherical at the inlet and outlet, so as to cut off the flow.

7. Self cleaning structure of sealing surface. When the ball leans away from the valve seat, the fluid in the pipeline passes through 360 ° evenly along the sealing surface of the ball, which not only eliminates the local scour of high-speed fluid on the valve seat, but also washes away the accumulation on the sealing surface, so as to achieve the purpose of self-cleaning.

Common materials:

Valve body: carbon steel WCB / A105 / LCB / LF2 / stainless steel CF8 / 304 CF8M/316 / CF3 / 304L / CF3M / 316L / F51 / 2205 / alloy steel forging or casting.

Ball: carbon steel / stainless steel / alloy steel forging nickel plating / chromium plating / spray welding hard alloy;

Seat support ring: carbon steel / stainless steel / alloy steel forging nickel plating / chromium plating / spray welding hard alloy;

Valve seat: PTFE, rptfe, Viton, nylon, Devlon, MOLON, PEEK / sealing surface spray welding, tungsten carbide, Stellite;

Stem: stainless steel / alloy steel / Inconel, etc

Common models: BQ347F, BQ347N, BQ347H, BQ347Y, BQ367F, BQ367N, BQ367H, BQ367Y,BQ947F，BQ947N BQ947H，BQ947Y, BQ967F, BQ967H, BQ967Y, BQ347F，BQ347H，BQ647Y, BQ667F, BQ667N， BQ667H, BQ667Y

Manufacturer: ZIPO VALVE & PUMP CO., LTD
