| Features & Benefits |
|
1.Flow rate up to 5.0 GPM [19.0 LPM] 3.Automatically turn on and off 5.Quiet operation 7.On demand & by pass use |
2.Can run dry without damage 4.Self priming & built-in check valve 6.Chemically resistant materials 8.Designed for spraying and fluid transfer |
| Product Name | SEAFLO 12 Volt dc Water Pump High Pressure Circulation with Battery |
| Pump Type | 5 Chambers Positive Displacement Diaphragm Pump |
| Max Flow Rate | 5.0 GPM [19.0 LPM] |
| Max Pressure | 60 PSI [4.1 Bar] |
| Voltage | 12 VDC, and 24V, 115V, 230V are available |
| Max Amp | 18.0 A |
| Fuse | 27.0 A |
| Switch Type | On Demand [Cut-off Switch], and none switch is available |
| Diaphragm Material | Santoprene |
| Valve Material | Viton, and EPDM is available |
| Duty Cycle | Continuous |
| Self Priming | 6' [1.8 m] suction |
| Max Fluid Temp | 140 °F [60 °C] |
| Inlet & Outlet Port | 3/4" Quick Connect, and contact us for more ports |
| Lead | 13" [33 cm] 14 AWG lead with 2-Pin connector |
The 52 Series is our Heavy-Duty water pump. It provides high volume water flow with reduced pump cycling, thanks to the large five-chamber diaphragm. Quick Attach Fittings make installation or replacement easy. These models are designed to run on water systems with no accumulator tank necessary, and up to five fixtures! It is also suited for use with a holding tank water system, as may be found in a boat, RV or remote cabin. It provides up to 5.0 gallons per minute. The 52-Series pumps are self-priming, and can run dry without damage, performance reliable. This automatic demand water system pump has a built-in pressure switch, which automatically starts and stops and stops the pump when the faucet is opened and closed. They are easy to install service and winterize.
| Product Show |
| Dimensions |
| Performance |
| Motor Heat Rise |
| Product Details |
Standard Pump Configurations
| Model | Voltage |
Open Flow GPM [LPM] |
Cut off Pressure PSI [BAR] |
Max Draw | Diaphragm | Valve |
| SFDP1-030-060-52 | 12 V | 3.0 [11.5] | 60 [4.1] | 10.0 A | Santoprene | Viton |
| SFDP2-030-060-52 | 24 V | 3.0 [11.5] | 60 [4.1] | 5.5 A | Santoprene | Viton |
| SFDP1-040-060-52 | 12 V | 4.0 [15.0] | 60 [4.1] | 13.0 A | Santoprene | Viton |
| SFDP2-040-060-52 | 24 V | 4.0 [15.0] | 60 [4.1] | 7.0 A |
Santoprene | Viton |
| SFDP1-050-060-52 | 12 V | 5.0 [19.0] | 60 [4.1] | 17.0 A | Santoprene | Viton |
| SFDP2-050-060-52 | 24 V | 5.0 [19.0] | 60 [4.1] | 9.0 A | Santoprene | Viton |
OEM/ODM service: Cut off pressure can be adjusted from 17 PSI [1.17 Bar] to 70 PSI [4.8 Bar]; Open flow can be adjusted from 0.8 GPM [3.0 LPM] to 5.3 GPM [20.0 LPM]. Material can be adjusted according to your requirement.
Package Infomation
|
|
Unit Pump Weight | 5.87 lbs [2.66 kg] |
| Selling Unit Size (L x W x H) | 11.18" x 6.26" x 5.51" [28.4 x 15.9 x 14.0 cm] |
|
| Selling Unit Weight | 6.42 lbs [2.91 kg] | |
| Master Carton Qty | 6 pcs / carton | |
| Master Carton Size (L x W x H) | 19.69" x 11.81" x 12.20" [50.0 x 30.0 x 31.0 cm] |
|
| Master Carton Weight | 43.66 lbs [21.80 kg] |
More flow and pressure are available, please contact us to get catalog and price list.
