SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System

SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System photo-1
SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System photo-2
SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System photo-3
SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System photo-4
SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System photo-5
SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System photo-6
SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System photo-7
US$ 25 - 31.2 MOQ: 8 Pieces
Key Specifications
Get Latest Price
Brand Name:
SEAFLO
Place of Origin:
China
Model Number:
SFDP1-030-045-33
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name SEAFLO
Place of Origin China
Model Number SFDP1-030-045-33
Power Electric
Structure Diaphragm Pump
Pressure Low Pressure
SEAFLO Profile

SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System

Product Description
Features & Benefits



1.Flow rate up to 3.0 GPM [11.3 LPM]
3.Automatically turn on and off
5.Quiet operation
7.On-demand use

2.Can run dry without damage

4.Self priming & built-in check valve

6.Chemically resistant materials

8.Designed for spraying and fluid transfer



Product NameSEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System
Pump Type3 Chambers Positive Displacement Diaphragm Pump
Max Flow Rate3.0 GPM [11.3 LPM]
Max Pressure45 PSI [3.1 Bar]
Voltage12 VDC, and 24V, 115V, 230V are available
Max Amp8.0 A
Fuse12.0 A
Switch Type

On Demand [Cut-off Switch], none switch is available

Diaphragm MaterialSantoprene
Valve MaterialViton, and EPDM is available
Duty CycleContinuous
Self Priming6' [1.8 m] suction
Max Fluid Temp140 °F [60 °C]
Inlet & Outlet Port1/2"-14 MNPT and, contact us for more ports
Lead13" [33 cm] 16 AWG lead



The 33 Series is our general-duty on-demand positive displacement pump. It provides reliable performance in high water flow, moderate pressure applications. This 3 chamber diaphragm pump provides up to 3.0 gallons per minute and is capable of self-priming up to 6vertical feet, and can run dry without damage. Serves 3 or more 1/2” (13 mm) outlets. This automatic demand water system pump has a built-in pressure switch, which automatically starts and stops when the faucet is opened and closed. They're easy to install, service and winterize.



Product Show



SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System



Dimensions



SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System


Performance


SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System


Motor Heat Rise



SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System



Product Details

SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System

Standard Pump Configurations

ModelVoltage

Open Flow

GPM [LPM]

Cut off Pressure

PSI [BAR]

Max DrawDiaphragmValve
SFDP1-030-045-3312 V3.0 [11.3]45 [3.1]8.0 ASantopreneViton
SFDP2-030-045-3324 V3.0 [11.3]45 [3.1]4.0 ASantopreneViton
SFDP1-028-045-3312 V2.8 [10.6]45 [3.1]4.0 ASantopreneViton
SFDP2-028-045-3324 V2.8 [10.6]45 [3.1]

2.0 A

SantopreneViton



OEM/ODM service: Cut off pressure can be adjusted from 17 PSI [1.17 Bar] to 60 PSI [4.10 Bar]; Open flow can be adjusted from 0.8GPM [3.0 LPM] to 3.1 GPM [11.7 LPM]. Material can be adjusted according to your requirement.



Application

SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System

Packaging & Shipping

Package Infomation

 Unit Pump Weight4.24 lbs [1.92 kg]
Selling Unit Size (L x W x H)

8.50" x 5.63" x 5.12" [26.4 x 14.3 x 13.0 cm]

Selling Unit Weight4.77 lbs [2.16 kg]
Master Carton Qty8 pcs / carton
Master Carton Size (L x W x H)

23.62" x 10.83" x 11.50"  [60.0 x 27.5 x 29.2 cm]

Master Carton Weight38.10 lbs [17.28 kg]



SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System



Company Information

SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment SystemSEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment SystemSEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System



More Products

SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System



SEAFLO 12V DC 3GPM 45PSI Water Pump Company For Water Treatment System



FAQ

Q: What is your MOQ?
A: 100 pieces in general, but no MOQ requirement for sample testing.



Q: Do you accept OEM/ODM service?
A: Yes. We are also the OEM/ODM supplier for many famous companies, such as Volvo, Bunnings etc.



Q: How can I pay for my order?
A: Please send order details to us. We will issue an order on Alibaba Trade Assurance, and send you the payment link.



Q: What is your terms of payment?
A: Payment≤3000USD, 100% in advance. Payment≥3000USD, 30% T/T in advance, balance against the copy of B/L. If you have another question, pls feel free to contact us.



Q: What is the delivery time?
A: It depends on the order quantity. It usually takes 15-25 days upon receipt of your 30% deposit by T/T. Sample can be delivered within 7 days.



Q: Can I buy different products in one container?
A: Yes, you can mix different models of pumps in one container.



Q: What is your warranty?
A: 1 year, and within 24 hours reply will be provided to solve customers' problems.



Q: What is your port of loading?
A: Xiamen port.



Q: Do you have oversea agents?
A: We dont have oversea agents for Agriculture and Industrial. But for SEAFLO pumps applied in Marine & RV, we have agents in USA, UK, Denmark, Spain, Australia, Turkey, Yemen, Lebanon etc.



Q: Can I get more info?
A: Please visit or www.seafloin.en.china.cn for more information.
