Help CenterXY-130 Hydraulic Core Drilling Machine Building Foundation Survey Equipment
Related Products
-
XY-44A Large Diameter Hydraulic Exploration Drilling MachineUS$ 4000 - 6000MOQ: 1 Set -
China High Quality XY-8 Hydraulic Coring Drilling Rig Large Diameter Well DrillUS$ 4000 - 6000MOQ: 1 Set
-
KY-200 Hydraulic Exploration Drilling Rig 200 Meters DepthUS$ 4000 - 6000MOQ: 1 Set
-
QTZ-4 50 Meters Deep Soil Exploration Drilling MachineUS$ 6000 - 8000MOQ: 1 Set
-
JZ-C Series Tractor-loaded Positive Circulation Water Well Drilling RigUS$ 9500 - 9800MOQ: 1 Set
Keywords: hydraulic water drilling machine price, water borehole drilling machine
1. The applications of XY-130 drilling machine
Water well,field irrigation well, engineering water well, precipitation well and so on; geological survey, geophysical exploration, road and high-rise building foundation exploration, wells, blasting holes and other drilling projects.
2. The Specifications of XY-130 drilling machine
Maximum opening hole diameter |
400mm |
Drilling depth |
130m |
End hole diameter |
75mm |
Drilling angel |
90-75° |
Dimension |
2.75X0.95X1.60m |
Drilling pipe diameter |
50mm |
Weight without power |
760kg |
Spindle | |
Spindle rotation speed |
71/142/310/20r/min |
Spindle stroke |
450mm |
Winch | |
Maximum lifting weight (single rope) |
2008kb |
Lifting speed |
17/35/75/160rm/s |
Wire-rope diameter: |
13mm |
Roll capacity |
35mm |
Mud pump | |
Type: horizontal single cylinder double action |
flow：180L/min |
Maximum pressure |
1.5mpa |
Working pressure |
0.7mpa |
Inlet pipe diameter |
50mm |
Outlet pipe diameter |
45mm |
Power | |
Diesel |
20hp |
Rated speed |
2200r/min |
Electric motor |
15kw |
Rated speed |
1460r/min |
