600 Meters Depth XYC-3 Vehicle-mounted Hydraulic Core Drilling Rig Deep Water Well Drilling Rig

Shandong Master Machinery Co., LTD
600 Meters Depth XYC-3 Vehicle-mounted Hydraulic Core Drilling Rig Deep Water Well Drilling Rig thumbnail-1
600 Meters Depth XYC-3 Vehicle-mounted Hydraulic Core Drilling Rig Deep Water Well Drilling Rig thumbnail-2
600 Meters Depth XYC-3 Vehicle-mounted Hydraulic Core Drilling Rig Deep Water Well Drilling Rig thumbnail-3
600 Meters Depth XYC-3 Vehicle-mounted Hydraulic Core Drilling Rig Deep Water Well Drilling Rig photo-1
600 Meters Depth XYC-3 Vehicle-mounted Hydraulic Core Drilling Rig Deep Water Well Drilling Rig photo-2
600 Meters Depth XYC-3 Vehicle-mounted Hydraulic Core Drilling Rig Deep Water Well Drilling Rig photo-3
US$ 59000 - 59200 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HuaxiaMaster
Place of Origin:
China
Model Number:
XYC-3
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
10 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HuaxiaMaster
Place of Origin China
Model Number XYC-3
Type Rotary Drilling Rig
Certification ISO 9001
After-sales Service Provided No overseas service provided
Warranty 6 Months
Weight no
Dimension(L*W*H) no
Power Type Diesel
Voltage no
Usage Water Well
Condition New
Power(W) 39kw

XYC-3 vehicle-mounted hydraulic water well drilling rig

1. Main features of XYC-3 vehicle-mounted hydraulic water well drilling rig

XYC-3 is a multi-functional hydraulic vehicle-mounted water well drilling rig.The drilling rig transmission system and hoist, mud pump and other important accessories are all installed on the chassis. The layout is reasonable and compact. And the operation is simple.

The drilling rig is equipped with high pressure and large flowBW-250 pump, which ensures the drilling depth and borehole diameter.

2. Applications of XYC-3 vehicle-mounted hydraulic water well drilling rig

· geological survey and exploration

· road and high-rise building foundation exploration

· all kinds of concrete structure inspection holes

· river embankments

· subgrade grouting holes

· drilling and direct grouting

· civil use water wells

· ground temperature central air conditioners

3. Parameters of XYC-3 vehicle-mounted hydraulic water well drilling rig

XYC-3 vehicle-mounted hydraulic water well drilling rig

Drill depth

30-600

Drill hole diameter

300-75

Diameter of the end hole

75

Drill angle

90-75

Spindle forward core speed

30-1050

Spindle reverse core speed

29-137

Spindle stroke

600

Main winch lifting force
(with single line)

3000

Main winch rope capacity

65

Lifting speed

0.3-1.9

Rope diameter

12.5

Drill mast height

7000

Drill effective height

6500

Driving drilling rod

59*53、70*63、79*89

Drilling rod diameter

42/50/60

Weight

3500

Engine

Model:Yunnei YN27





BW-250 mud pump

Rated flow (l/min)

250

Rated power(mpa)

7

Driving power(kw)

15

Host weight(kg)

500

Dimension(mm)

1110*994*665

Chassis

Vehicle（Pictures of vehicle-mounted drilling rigs for reference only）


Product Tags: Truck Mounted Drilling Rig , Hydraulic Drilling Rig , Tractor Mounted Drilling Rig
