Zero buoyancy underwater white floating cable

FOB Price

US$ 0.3 - 3.5 / Meter

1000 Meters(Min. Order)

Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	KKC	Place of Origin	Shanghai, China
Model Number	ROV Cable	Application	Industry
Conductor Material	Copper
Number of Conductors	Multi-core	Insulation Material	PE

Product Description

Zero buoyancy underwater white floating cable

Floating Cable relies on foam core extrusion capabilities to achieve precise cable buoyancy requirements. It is flexible, movable,UV-stable, good bendability, and abrasion-resistant and may be fitted with choice of jackets to achieve resistance to various chemicals including acids, salt water, oil, and gasoline. Cable is suited for powering and controlling robotic cleaning systems in swimming pools and aquarium facilities as well as marine applications and submersible environmental pumping systems

_Conductors:	_{Bare copper or Tinned copoer stranded}
_Insulation:	_{HT 105℃ PVC insulation}
_{Inner Jacket:}	_{Press extruded TPE}
_Filler:	_{Two filler inside}
_Jackets:	_{Foam PVC/TPE}
_{Working life:}	_{Working life <25years}
_Depth:	_{300/500 VOLTS}
_Feature:	_{Property Water-proof/Oil-resistant/Cold-resistant}

Specification

Specification	Insulation Diameter(mm)	Sheath Diameter(mm)
2 x 12 AWG	4.0	18.0
2 x 16 AWG	2.9	12.4
2 x 18 AWG	2.4	10.2
2x16AWG + 1x18AWG	2.9/2.4	13.5
2x16AWG + 2x22AWG	2.9/2.0	13.2
4x16AWG + 2x20AWG	2.9/2.0	17.8
Coxial + 3x2x16AWG	/	/

Products Show

The deep sea cable is filled with a special gel. This ensures a form stable behavior at up to 500 bars lateral pressure.

3.5 mill. bending cycles longitudinall and transversally watertight

Sea water resistant

Pressure resistant up to 500 bars

Applications

ROV Tether/ROV Umbilical/Underwater Floating Cable

Cable is suited for powering and controlling robotic cleaning systems in swimming pools and aquarium facilities as well as marine applications and submersible environmental pumping systems

Certifications

Product Process

Packing & Delivery
