304 316 312 SS Stainless Pipe Stainless Heat Exchanger Tubes

Name: 304 316 312 SS Stainless Pipe Stainless Heat Exchanger Tubes
Brand: jetvision
Availability: InStock

FOB Price

USD $500 - $1000 / Ton

1 Ton(Min.Order)

Supply Ability 80000 Ton / Tons per Month
Port shanghai port and other ports
Payment TermsT/T L/C PayPal Other
Delivery Detail30 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	jetvision	Place of Origin	China
Model Number	010	Certification	ISO
Thickness	0.5-8mm , customized	Type	Seamless
Application	Heat Exchanger, Boiler	Standard	ASTM, AISI
Outer Diameter	12.7-159mm , customized	Welding Line Type	Seamless
Steel Grade	300 Series

Product Description

304 316 312 SS Stainless Pipe Stainless Heat Exchanger Tubes

Stainless heat exchanger tubes is suitable for water cooled unit, water source heat pump, air cooled pump and air cooled heat pump unit. The product is applying for refrigerants of R22, R134a, R407C and R410A etc. Jetvision specialized in Stainless heat exchanger tubes with over 17 years. All product has passed ISO9001, ISO14001, OHSAS18001 etc.

Application : For Boiler , tube heat exchanger , condenser , evaporator , super heater and so on .

Used in oil industry , petrochemical industry , ice factory , light manufacturing , pharmaceutical industry energy industry and so on .

Product Specification

Material	TP304,TP304H,TP316, TP316, TP316L,TP321
Specification	OD: 12.7-159mm WT: 0.5-8mm
Standard	ASTM A213,ASME SA213,GB13296, JIS3463,DIN17458, EN10216-5
Surface Finish	Annealed & pickled, bright annealing, polished
Length	6M or customized
Packing	bundles, wooden box packing or as customer requested
Application	Heat Exchanger, Boiler
Payment Term	T/T; Irrevocable L/C at sight

4. Chemical Requirements

Chemical Composition %
Grade	UNS Designation	C	Mn	P	S	Si	Cr	Ni	Mo	Other
TP304	S30400	0.08	2	0.045	0.03	1	18.0-20.0	8.0-11.0	…
TP304L	S30403	0.035	2	0.045	0.03	1	18.0-20.0	8.0-13.0	…
TP304H	S30409	0.04-0.10	2	0.045	0.03	1	18.0-20.0	8.0-11.0	…
TP316	S31600	0.08	2	0.045	0.03	1	16.0-18.0	11.0-14.0	2.00-3.00
TP316L	S31603	0.035	2	0.045	0.03	1	16.0-18.0	10.0-14.0	2.00-3.00
TP316H	S31609	0.04-0.10	2	0.045	0.03	1	16.0-18.0	11.0-14.0	2.00-3.00
TP321	S32100	0.08	2	0.045	0.03	1	17.0-19.0	9.0-12.0	…	N: 0.1
TP321H	S32109	0.04-0.10	2	0.045	0.03	1	17.0-19.0	9.0-12.0	…	N: 0.1
										Ti: 4(C+N) min;
										0.70 max
TP347	S34700	0.08	2	0.045	0.03	1	17.0-19.0	9.0-13.0	…
TP347H	S34709	0.04-0.10	2	0.045	0.03	1	17.0-19.0	9.0-13.0	…

Packing &shipping

Packing Details : Export standard package, bundled or be required.

The inner size of container is below:

20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high)

40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high)

40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high)
