Automobile CR825 All In One Line Multifunctional Common Rail Diesel Fuel Injector Pump Testing Equipment
US$ 18,000 - 18,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
DONGTAI
Place of Origin:
Shandong, China
Model Number:
CR825
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO or any port china
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Taian Dongtai Common Rail Pump and Injector Test Bench CR815US$ 6,400 - 8,300MOQ: 1 Set -
CR815 Common Rail Test BenchUS$ 6,500 - 6,500MOQ: 1 Set
-
Factory Supply Common Rail Injector Tester Diesel Fuel Pump Test Bench Cr815US$ 6,400 - 6,500MOQ: 1 Set
-
COMMON RAIL PUMP INJECTOR TEST BENCH CR815US$ 6,400 - 6,500MOQ: 1 Set
-
CRS300 Common Rail System Test BenchUS$ 3,480 - 3,660MOQ: 1 Set
Brand Name
DONGTAI
Place of Origin
Shandong, China
Model Number
CR825
Power
Electronic
Product Description
Automobile CR825 All In One Line Multifunctional Common Rail Diesel Fuel Injector Pump Testing Equipment
Function:
1, All common rail injector (include piezo )
2,All common rail pumps
3,Denso HP0 PUMP testing
4,EUI/EUP testing
5,HEUI injector testing
6,HEUI pump testing
7,CAT 320D pump testing
8,Electronic pump testing
9,Measurement unit testing
10,Armature stroke AHE test
1, All common rail injector (include piezo )
2,All common rail pumps
3,Denso HP0 PUMP testing
4,EUI/EUP testing
5,HEUI injector testing
6,HEUI pump testing
7,CAT 320D pump testing
8,Electronic pump testing
9,Measurement unit testing
10,Armature stroke AHE test
Optinal Function:
1,VP37/VE37 electronic pump
2, Vp44 pump test
3, TICS electronic pump
4, Electronic unit pump
5, General pump test(E2 pump)
Multifunctional BC-CR825 common rail piezo injector pump test bench can test HP0 pump
MAIN CONFIGURATION
1.Motor power:22KW
2.Industrial PC with touch screen
3.Compressor cooling
4.Oil tank(including heating,refrigeration,liquid level detection,temperature detection)
5.Diesel tank(including heating,refrigeration,liquid level detection,temperature detection)
6.Flow meter(German ZDM) detecting the fuel injection flow rate
7.Flow meter(German ZDM) detection of common rail pump
8.Flow meter(German KRACHT) to detect oil flow
9.Flow meter(German KRACHT) detection of diesel oil return flow
10.2sets of BOSCH common rail +DRV
11.Oil tank temperature sensor
12.Diesel fuel tank temperature sensor
13.Diesel supply temperature sensor
14.Diesel return temperature sensor
15.Oil pressure sensor
16.Diesel supply pressure sensor
17.Diesel return pressure sensor
18.Diesel pump internal pressure sensor
19.Oil pressure closed loop control module
20.The device is convenient to move and position the roller
FUNCTION CHARACTERISTIC
1.Test all the manufacturers of common rail injector
2.Test all the manufacturers of piezo injector
3.Test all the manufacturers of common rail pump
4.Test D-ENSO HP0 pump
5.Test C-AT common rail (HEUI) injector
6.Test C-AT common rail (HEUI) engine oil pump
7.Test C-AT 320D common rail pump (the world's first successful development)
8.Test EUI/EUP (can adjust the lift but not to change the camshaft)
9.Test VP44 VE VP37 pump
10.Test RED3 RED4 TICS Z-EXEL electronic control pump
11.Drive circuit board(solenold valve electric parameters to enhance the voltage
current,time,pull in voltage ,current,time,keep voltage ,current,time,according to the setting of parameters of production factory)
12.Accept the speed sensor ,encode signal,high speed solenoid valve drive signal.Accept the speed sensor ,encoder signal,output 2 PWM drive signal, 2 way solenoid valve drive signal,1 high speed solenoid valve drive signal.
Driving signal waveform can be programed.
NOTE:
Now the BC-CR825 support the coding function and Team Viewer
More detailed photos of BC-CR 825
TECHNICAL PARAMETERS
Main power |
380V AC 220V AC(Optional) |
Frequncy |
50Hz/60Hz |
Mian motor |
22KW |
Oil motor HP/ Flow |
0.19KW / 13L/MIN |
Control circuit voltage |
DC12V/24V 350W |
Oil tank volume |
30L |
Temperature control |
Heating/Forced cooling |
Flowmeter(injection) |
4-550ml/min |
Flowmeter(fuel flow back) |
1-400L/H |
Center distance between motor and working bench |
125mm |
Outlook size net |
(LXWXH)2250X1260X1920 |
Phase |
Three single(optional) |
Current |
45A(MAX) |
Main motor rotation |
0-4000 RPM/MIN |
Diesel motor HP /Flow |
0.19KW / 13L/MIN |
ECU internal voltage |
0-200V DC(MAX) |
Diesel Tank volume |
52L |
Max rail pressure |
180MPa,240MPa(Optional) |
Flowmeter(fuel supplying) |
1-400L/H |
Flowmeter(Oil) |
5-600L/H |
Weight |
1700KG |
Wooden cage |
(LXWXH)2350X1500X2100
|
