Product Model：LRSU9A42-AC
Product Name：2 Port PCIe x4 10Gb/s to USB 3.1 Type-A +Type-C Adapter
Main Chipset：ASM1142 & ASM1543
Interface Type：1*USB3.1 Type-A & 1*USB3.1 Type-C
Host Bus Type：PCIe 3.0 x4
LRSU9A42-AC can convert PCIe to USB 3.1 type-A and USB 3.1 Type-C ,the maximum transmission speed of USB 3.1 gen-ii can reach 10Gbps, support the hot plug function of USB device, especially the personal computer, and the consume electronic products and communication equipment provide faster and higher speed.
• Support PCI Express Gen III X2
• compatible with USB 3.1 specification Gen2
• compatible with USB plus SCSI protocol revision 1.0
• USB3.1 Gen-ii delivers up to 10Gbps
• compatible with USB 3.1 specification revision v2.0/1.0
• support USB data transfer rate of 10G/5G/480/12/1.5 Mbps
• extend an external USB3.1 super-fast +C port (DFP) on the system
• the maximum output current of type-c is 5V/3000mA
• the maximum output current of type-a is 5V/900mA
• 1 Type C female head, 1 external USB3.1 interface and 1 internal SATA power supply
• overcurrent protection is built into each USB port
• support Multiple INs
• support remote wake-up function for devices such as USB keyboard or mouse
• support Control, Bulk, Stream, Interrupt, Isochronous transmission type
