construction BWG12 bright black iron annealed soft wire
We produce the annealed wire with high-quality low carbon raw materials through wire drawing, anneal process. Its soft and has good stretching resistance. The finished products are smeared with slushing oil. So they are not apt to rust. We can tie up the products according to customers requirements, ranged from1 to 50 kg each bundle.
Soft annealed wire, also known as annealed wire, offers excellent flexibility and softness through the process of oxygen free annealing. Soft annealed wire is mostly used in woven wire mesh or as wire tie.
Iron wire can be processed into cut wire or U type wire for binding uses.
We offer two kinds of annealed wire, bright annealed and black annealed wire.
Black annealed wire gets its name from its plain black color.
Wire Materials: Carbon steel wire.
Uses: Black annealed wire is mainly processed into coil wire, spool wire or big package wire.
Or further straightened and cut into cut wire and U type wire.
Annealed wire is used as tie wire or baling wire in building, parks and daily binding.
Packing: Spools, Coils.
Wire Diameters: Similar to galvanized iron wire, from 5mm to 0.15mm (wire gauge 6# to 38#).
Detailed introduction
Standard Gauge: from 5# --38# (0.17mm-4.5mm)
Tensile Strength: 35-55kg/mm2
Elongation rate: 10%-25%
Characteristics and Application: Strong flexibility plasticity and a wide rang of uses such as daily binding construction use, industrial use handcraft making net etc.
Commom packing: 0.5kg -1000kgs/coil, plastic film inside then wrapped with white or other color PVC weaving bag or hessian cloth outside.
| Wire Gauge | SWG in mm | BWG in mm | In Metric System mm |
| 8# | 4.06 | 4.19 | 4.00 |
| 9# | 3.66 | 3.76 | - |
| 10# | 3.25 | 3.40 | 3.50 |
| 11# | 2.95 | 3.05 | 3.00 |
| 12# | 2.64 | 2.77 | 2.80 |
| 13# | 2.34 | 2.41 | 2.50 |
| 14# | 2.03 | 2.11 | - |
| 15# | 1.83 | 1.83 | 1.80 |
| 16# | 1.63 | 1.65 | 1.65 |
| 17# | 1.42 | 1.47 | 1.40 |
| 18# | 1.22 | 1.25 | 1.20 |
| 19# | 1.02 | 1.07 | 1.00 |
| 20# | 0.91 | 0.89 | 0.90 |
| 21# | 0.81 | 0.813 | 0.80 |
| 22# | 0.71 | 0.711 | 0.70 |
| 23# to 34# also available for galvanized iron wire | |||
| Black Anneald Wire | ||||
| Wire Diameter | Strength | Packing | Weight | Application |
| 0.16mm-0.6mm | 30-40kg | Coil or spools | 2-100kgs | Daily binding construction Industrial use handcraft making net etc. |
| 0.6mm-5.0mm | 30-40kg | Big package | 100-800kgs | |
| 0.16mm-0.6mm | 60-70kg | Coils or spool | 2-100kgs | |
| 0.6mm-5.0mm | 60-70kg | Big package | 100-800kgs | |
Product Packaging:Coil wire, bobbins wire,spool wire,cut wire in different.
1.Plastic inside and gunny outside
2.Plastic inside and weaving plastic outside
3.Plastic inside and water-proof paper outside
4.In carton box,then on enclosed plywood pallet boxes
5.Or as your requirement
|
|
|
|
|
|
Black steel wire specifications:
Wire diameter: 3.3 mm / 3.5 mm / 3.75 mm / 5 mm.
Weight of each coil: 200 kg.
Inside diameter of each coil: 476 mm.
Packing: Weaving bags and Plastic.
Yield Point: 320 N/mm2.
Tensile Strength: 480 N/mm2.
Elongation: 33% (Note: 5.5 mm wire rod before wire drawling).
Elongation: 5-6% (Note: Diameter 3.3 mm wire rod drawling).
Chemical: Carbon: 0.09% Si: 0.17% Mn: 0.57% P: 0.024% S: 0.02%.
Black annealed wire and twist wire specifications:
Black annealed wire:
Diameter: 1.15 mm.
Tensile strength: 36.1 kg/mm2, 36.4 kg/mm2.
Elongation: 24%.
Packing: 4.8 kg × 5 /coil / internal diameter 23 cm, outer diameter 34 cm.
Twisted wires:
Diameter: 1.16 mm.
Tensile strength: 40.9 kg/mm2, 39.4 kg/mm2.
Elongation: 25%.
Packing: 4.6 kg × 5 than 11 coil make one bundle internal diameter of coil: 37 cm, outer diameter 47 cm.
Black annealed binding wire specification:
Thickness: 1.00 mm.
Width: 3/4".
Technical: cooled rolled.
Surface treatment: polished.
Application: construction.
Color: bright.
Black annealed binding wire.
Material: Q195.
Weight: 25 kg/coils.
Wire grade: BWG16, BWG18, BWG20.
Black Annealed Wire 2.9 mm, 25 kg/coil.
Packaging: PVC inside, hessian cloth outside.
10 coils/bundle secured with 4 nos steel straps.
Specs: Tensile strength 350 n/mm2 (Very soft, annealing for 9 hours).
Covered with oil for anti rusting.
