Help CenterDEEPSEA CONTROL PANEL DSE5220
Related Products
Description
The DSE5220 is an Automatic Mains Failure Control Module designed to automatically startand stop diesel and gas generating sets that include non electronic engines. The modulealso provides excellent engine monitoring and protection features.
The module has the ability to monitor under speed, over speed, charge failure, emergencystop,low oil pressure, high engine temperature, fail to start, fail to stop, under/over generator volts,over current, under/over generator frequency, low/high DC battery volts,low fuel alarm and loss of the speed sensing signal. The module displays fault conditions on the LCD display and via the LED indicators on the front.
The DSE5220 also has the ability to monitor a mains (utility) supply. Upon detection ofa mains (utility) failure the module automatically starts the generating set. Once the mains (utility) power has been restored it instructs the generating set to stop.
Environmental Testing Standards
Electro-magnetic compatibility
BS EN 61000-6-2
EMC Generic Immunity Standard for
the Industrial Environment
BS EN 61000-6-4
EMC Generic Emission Standard for the Industrial Environment
Electrical safety
BS EN 60950
Safety of Information Technology Equipment, including Electrical Business Equipment
Temperature
BS EN 60068-2-1
Ab/Ae Cold Test -30 °C
BS EN 60068-2-2
Bb/Be Dry Heat +70 °C
Vibration
BS EN 60068-2-6
Ten sweeps in each of three major axes
5 Hz to 8 Hz @ +/-7.5 mm,
8 Hz to 500 Hz @ 2 gn
Humidity
BS EN 60068-2-30
Db Damp Heat Cyclic 20/55 °C
@ 95% RH 48 Hours
BS EN 60068-2-78
Cab Damp Heat Static 40 °C
@ 93% RH 48 Hours
Shock
BS EN 60068-2-7
Three shocks in each of three major axes
15 gn in 11 mS
DEGREES OF PROTECTION
PROVIDED BY ENCLOSURES
BS EN 60529
IP65 - Front of module when installed into the control panel with the supplied sealing gasket.
