Description
The DSE7320 is an Auto Mains (Utility) Failure Control Module suitable for a wide variety of single, diesel or gas, gen-set applications.
Monitoring an extensive number of engine parameters, the modules will display warnings, shutdown and engine status information on the back-lit LCD screen, illuminated LEDs, remote PC and via SMS text alerts (with external modem).
The DSE7320 will also monitor the mains (utility) supply. The modules include USB, RS232and RS485 ports as well as dedicated DSENet® terminals for system expansion.
Key features
• Reactive power protection
• 4-Line back-lit LCD text display
• Five key menu navigation
• Front panel editing with PIN protection
• Customisable status screens
• Power save mode
• Support for up to three remote display units
• 9 configurable inputs
• 8 configurable outputs
• Flexible sender inputs
• Configurable timers and alarms
• 3 configurable maintenance alarms
• Multiple date and time scheduler
• Configurable event log (250)
• Tier 4 CAN engine support
• Integral PLC editor
• Easy access diagnostic page
• CAN and Magnetic Pick-up/Alt. sensing
• Fuel usage monitor and low fuel alarms
• Charge alternator failure alarm
• Manual speed control (on compatible CAN engines)
• Manual fuel pump control
• Engine exerciser
• “Protections disabled” feature
• kW & kV Ar overload protection
• Reverse power (kW & kV Ar) protection
• LED and LCD alarm indication
• Power monitoring (kW h, kV Ar, kV A h, kV Ar h)
• Load switching (load shedding and dummy load outputs)
• Automatic load transfer (DSE7320)
• Unbalanced load protection
• Independent Earth Fault trip
• True dual mutual standby with load balancing timer (DSE7310 only)
• USB connectivity
• Backed up real time clock
• Fully configurable via DSE Configuration Suite PC software
• Configurable display languages
• Remote SCADA monitoring via DSE Configuration Suite PC software
• User selectable RS232 and RS485 communications
• Configurable Gencomm pages
• Advanced SMS messaging (additional external modem required)
• Start & stop capability via SMS messaging
• Additional display screens to help with modem diagnostics
• DSENet® expansion compatible
Key benefits
• 132 x 64 pixel ratio display for clarity
• Real-time clock provides accurate event logging
• Multiple date and time scheduler
• Set maintenance periods can be configured to maintain optimum engine performance
• Ethernet communications (via DSE860/865 modules), provides advanced remote monitoring at low cost
• Modules can be integrated into building management systems (BMS)
• Increased input and output expansion capability via DSENet®
• Licence-free PC software
• IP65 rating (with supplied gasket) offers increased resistance to water ingress
• PLC editor allows user configuraPackaging & Shippingble functions to meet specific application requirements
Focus on Truck and generator Parts Solution
With an aim of ensuring maximum efficiency and quality of Holdwell products and service,we build global cooperation with our partners and constantly develop and promote innovation on both sides.
Our total quality management in purchasing is based on the transfer of purchasing requirements of our customers to suppliers.We carefully follow the requirements of standard TS16949 and the European Business Excellence Model(EFQM.)
1. Q: Are you a factory or trading company?
A: We are a trading company with factory.
2. Q: Where is your company located? How can I visit there?
A: Our company is located in Hangzhou, Zhejiang, China, near Shanghai. You are warmly welcomed to visit us!
3. Q: How can I get some samples?
A: Please connect me for samples, and my phone number: +86 18768106189
4. Q: Can the price be cheaper?
A: Of course, you will be offered a good discount for big amount.
Payment Terms
T/T, Western Union,Paypal are the payment methods we accept at present.
Shipping
The delivery time is about 2-3 workdays. It takes about 3-15 days to worldwide, Please note us your contact details include your phone number for easy contacting from shipping company officer.
Feedback
1. Customer satisfaction is completely guaranteed. If for any reason you are unsatisfied with your order, please contact us first before you leave the feedback.
2. We will do our best to take care of you and if you have any questions please do not hesitate and feel free to contact us at:
