Home > Industrial Equipment & Components > Bearing > Slewing Bearing > China YRT150 for CNC Machine Tool Rotary Tables
EUR 1 - 10000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
HONB
Place of Origin:
China
Model Number:
YRT150
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Qingdao
Delivery Detail:
5 days
Related Products
-
INA YRT180 Slewing Bearings/axial and Radial Bearings YRT180EUR 1 - 10000MOQ: 1 Piece -
High Precision YRT200 Axial and Radial BearingsEUR 1 - 10000MOQ: 1 Piece
-
Hot Sell YRT Slewing Bearings YRT260EUR 1 - 10000MOQ: 1 Piece
-
Good Quality YRT325 Rotary Table BearingsEUR 1 - 10000MOQ: 1 Piece
-
Good Price China YRT395 Axial and Radial Rotary Table BearingsEUR 1 - 10000MOQ: 1 Piece
Brand Name
HONB
Place of Origin
China
Model Number
YRT150
Feature
Other, Axial and Radial bearings
Seals Type
No seals
Outside Diameter
240, 240
Bore Size
150, 150
Gear Options
Nongeared
YRT basic rotary table Bearings are designed with a radial full roller, two groups of axial needle Roller, cage assembly, an out ring, a L-section Inner ring and the second ring. the out ring and inner ring have fixing holes. Added preload after fitting simplified the unit construction,Shorten the work of fixing, Lowered the high on fixing. so this kind of bearing is particularly suitable for the situatin of High precision, high stiffness and the Union loads with low speed such as index tables and revolving milling heads.See Fig
*this kind of Bearing have axial and radial running precision for your chosen.(HONBbearing05)
Contact person: Anna Feng
Tel: +86 379 63086182
Fax:+86 379 63086177
Fax:+86 379 63086177
Mob: +86 13598495189
Whatspp: +86 13598495189
Skype: bearing3_01
Website:
Whatspp: +86 13598495189
Skype: bearing3_01
Website:
| Type | size | fixing hole | |||||||||||||
| d | D | H | H1 | H2 | C | d1 | dn | dm | inner ring | outer ring | |||||
| unit：mm | do | ds | Ts | QTY 4) | dL | QTY 4) | |||||||||
| mm | mm | ||||||||||||||
| YRT150 | 150 | 240 | 40 | 26 | 14 | 12 | 214 | 165 | 225 | 7 | 11 | 6.2 | 34 | 7 | 33 |
| Type | Screw connection QTY | Connect screws holes | Pitch1）t | Tightening torque of screw | Basic load rating | Limited speed5） | Friction Moment3） | weight | ||||
| Axial | Radial | |||||||||||
| Dynamic | Static | Dynamic | Static | |||||||||
| MA2） | Ca | Coa | Cr | Cor | Grease | |||||||
| G | QTY | QTYXt | N m | KN | r/min | Nm | ≈Kg | |||||
| YRT150 | 2 | M8 | 3 | 36*10° | 14 | 112 | 630 | 56 | 170 | 320 | 10 | 6.2 |
