Help CenterPCB PCBA SMT DIP
Related Products
-
Specialized in PCB Assembly More Than 15 Years (PCBA)US$ 0.1 - 100MOQ: 1 Set -
Provide 1 to 30 Layers PCB and PCB Assembly, With Own Factory More Than 15 YearsNegotiableMOQ: 1 Piece
-
Specialized in PCB Assembly More Than 15 Years.US$ 0.1 - 100MOQ: 1 Set
-
Flexible and Rigid Printed Circuit Board FPC R&F PCBUS$ 0.1 - 8.88MOQ: 1 Piece
-
AA1050 H24 Aluminum Sheet for PCB Chemical Etching 0.5mm 1mm 1.5mm 2mm Smooth GradeUS$ 2.6 - 5.2MOQ: 100 Kilograms
Product:
1. Layers : 2 to 30 layers rigid PCB
2. Materials: FR4,FR5,High-Tg，Halogen Free，Rogers，Cem-1，Cem-3,Taconic，Rigid-flex，Teflon，Aluminum PCB, etc.
3. Board Thickness: 0.2mm-6.0mm
4. Board Thickness Tolerance: ±0.10mm
5. Min. Track Width: 3mil
6. Min. Track Space: 3mil
7. External Cu Thickness: 18um-210um（HOZ-6OZ）
8. Internal Cu Thickness: 18um-210um（HOZ-6OZ）
9. Drilling Bit Size(CNC): 0.15mm-6.50mm
10. Finished Hole Dimension: 0.1mm-6.0mm
11. Hole Tolerance: ±0.05mm
12. Hole Position Tolerance: ±0.05mm
13. Aspect Ration: 10:1
14. Max. Panel Dimension: 646mm*1200mm
15. Solder Mask: Green，Blue，White，Black，Red，Yellow，Purple, etc.
16. Impedance Control: ±10%
17. Surface Finishing: HASL，HASL(Lead Free)，Immersion Gold，Immersion Tin，Immersion Silver，OSP，Hard Gold( up to 100u”)
18. Special Requirement: Buried & Blind holes, Counter Sink, Counter Bore, Rigid-flex board, etc.
