Indoor LED Display

Negotiable MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

China

Jiangsu Lifewatch Information Technology Co.,Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Item	Model	LW0P4	LW0P5	LW0P6	LW0P8	LW0P10
Module	LED	SMD2525	SMD2727	SMD3535	SMD3535	SMD3535
	Pixel Pitch	4mm	5mm	6mm	8mm	10mm
	Resolution	64*32	64*32	32*32	32*16	32*16
	Dimension	256mm*128mm	320mm*160mm	192mm*192mm	256mm*128mm	320mm*160mm
Cabinet	Cabinet Resolution	144*144	128*128	96*96	96*96	64*64
	Cabinet Dimension	576mm*576mm	640mm*640mm	576mm*576mm	768mm*768mm	640mm*640mm
	Material	aluminum die casting	Metal Cabinet	Metal Cabinet	Metal Cabinet	Metal Cabinet
	View Angle	140°H，120°V	160°H，120°V	160°H，120°V	160°H，120°V	160°H，120°V
	Brightness	≥6800cd/m²	≥6000cd/m²	≥6500cd/m²	≥6500cd/m²	≥7000cd/m²
General	Max. Consumption	1000W/㎡	980W/㎡	980W/㎡	900W/㎡	880W/㎡
	Refresh Frequency	≥1920Hz	≥1920Hz	≥1200Hz	≥1200Hz	≥3600Hz
	Best View Distance	4-50m	5m-50m	6m-50m	8m-50m	10m-50m
	View Angle	H ≥140° V≥120°	H ≥160° V≥120°	H ≥160° V≥120°	H ≥160° V≥120°	H ≥160° V≥120°
	Scanning	1/8 scanning	1/8 scanning	1/8 scanning	1/8 scanning	1/2 scanning
	White Balance	750-1000(optional)
	Color Temperature(K)	3200-9600(optional)
	Gray level	65536
	Color Gamut	16bit
	Lifespan	＞100000HRS
	Working Temperature	-10℃～+50℃
	Working Humidity	10%～98%RH
