1000v Cable Rov Yellow / Orange Sheath Cable Anti-seawate & Acid-base
- Shanghai
- T/T D/P D/A Credit Card Cash
- 7 days
You May Like
-
Yellow / Orange Sheath Acid-base & Oil-resistant Cable Subsea Umbilical Cable
-
Floating Cable Cable Acid-base With Orange Sheath
-
Anti-microbial Erosion Cable Sheath Orange / Blue Rov Umbilical Cable
-
Cable Oil-resistant For Marine Applications Cable Rov
-
Rov Cable With Blue Sheath Color Cable Anti-dragging
-
With Orange Sheath Rov Wire Umbilical Cable Anti-seawate & Acid-base
Product Details
| Jacket | ETFE | Insulation Material | FEP | |
| Conductor Material | Copper | |||
| Brand Name | RS | Place of Origin | China |
Product Description
Applications:
It is mainly used for ROV unmanned remotely operated vehicle and
equipment control signal line, as well as a series of underwater work
such as: monitoring，mapping, underwater observation video, inspection
and construction. It is characterized by high flexibility, high
toughness, bending resistance, distortion resistance, abrasion
resistance, Nick resistance, high pressure resistance, electronic
interference resistance and seawater resistance.
Description:
ROV cable - underwater camera cable, underwater salvage equipment cable, underwater construction applications with underwater mechanical arm robot cable, submarine pipeline detection and maintenance robot cable, submarine desilting and dredging robot cable, with hydraulic cutter and other operating tools special cable ocean detection cable.
Specifiation:
Model Number
| RS
|
Specifications
| ROV Cable
|
Outer Diameter | 5±0.2MM |
Conductor
| Anodized Bare Copper Wire
|
Insulation
| Special Seawater-proof PE Material
|
Core color
| Color Separation
|
Tensile Structure | Imported Kevlar Bulletproof Wire |
Tensile Strength
| 80kg
|
Wrapping Material
| High Quality Lightweight Nonwoven
|
Cable Shield
| None
|
Inner Sheath | Foam-proof Seawater-specific Polyether PolyurethaneMaterial (Anti-seawater, oil-resistant, acid-base, corrosion-resistant, anti-dragging, anti-microbial erosion)
|
Outer Sheath | Polyurethane Glossy Anti-seawater Corrosion Special Material |
Temperature Range
| Fixed laying: -40°C~+90°C |
Mobile Installation
| -30°C~+80°C
|
Radiation Resistance
| 8x107cj/kg (water resistant cable 5x107 cj/kg)
|
Rated Voltage
| 300/300V
|
Test Voltage
| 1500V |
Nsulation Material:
FPE, PE, or HT PVC 105 ℃
Type:Low Voltage, Low Voltage
Application: underwater Float water
Outer Jacket: FEP, Foam TPE Inner Jacket Press extruded TPE
Conductor: Pure Copper, Tinned Copper
Test Voltage: 1000V, 1 minSheath
Color: Yellow, Blue, Orange
