Features:
1.two-tank, precision four-post structure of the self-balancing connecting rod which can maintain the equal pressure of each cutting position
2.Series B machine has super long stroke setting for adapt to the super thick material and super high die cutters.
3.When pressing the cutting board and touching the cutter, it can cut automatically and slowly to make that no size error between the uppermost layer and lowermost layer of the cutting material.
4.The unique setting construction, combine with the cutting knife and cutting height which can make high-speed stroke simple and accurate.
5.Central automatic lubrication systems which can ensure the precision and durability of the machinery.
Machine Specification:
Model |
HTA-730T |
HTA-740T |
HTA-750T |
Cutting Force |
30Tons |
40Tons |
50Tons |
| Stroke Range | 50-250mm |
50-250mm | 50-250mm |
| Cutting Area | 510*1250mm |
610*1250mm | 710*1250mm |
| Motor Power | 2.2kw | 4kw | 4kw |
| Machine Dimension | 1985*950*1380mm | 1985*1050*1420mm | 1985*1050*1400mm |
| Machine Weight | 1600kg | 2200kg | 2000kg |
| 1 | 30T Manual Sponge die cutting machine | https://youtu.be/QhVgBsS0OSg |
| 2 | Horizontal and vertical slitting machine epe foam plastic cutting machine | https://youtu.be/BJrsh-lzw4Y |
| 3 | single side plastic sheet die cutting machine with robot arm | https://youtu.be/pIYhox698Z0 |
| 4 | blister packaging hydraulic cutting machine | https://youtu.be/AJEtDZgaiAI |
| 5 | All in one full automatic positive and negative multi station machine | https://youtu.be/FykJJhMlo3Q |
| 6 | High speed Hydraulic Plastic disposable container Cutting Machine | https://youtu.be/ic8GI8cPv0o |
| Model | HTA-730T | HTA-740T | HTA-750T | HTA-760T | HTA-780T | HTA-7100T |
| cutting Force | 30Tons | 40Tons | 50Tons | 60Tons | 80Tons | 100Tons |
| stroke | 50-250mm | 50-250mm | 50-250mm | 50-250mm | 50-250mm | 50-250mm |
| cutting Area | 510X1250mm | 610X1250mm | 710X1250mm | 810X1250mm | 810X1400mm | 810X1400mm |
| Motor power | 2.2kw | 4kw | 4kw | 5.5kw | 7.5kw | 7.5kw |
| Dimension |
1985X950 X1380mm |
1985X1050 X1400mm |
2030X1150 X1420mm |
2085X1250 X1450mm |
2385X1250 X1500mm |
2385X1250 X1530mm |
| Weight | 1600kg | 2000kg | 2500kg | 2800kg | 4000kg | 4600kg |
| Model | HTA-830T | HTA-840T | HTA-850T | HTA-860T | HTA-880T | HTA-8100T |
| cutting Force | 30Tons | 40Tons | 50Tons | 60Tons | 80Tons | 100Tons |
| stroke | 50-250mm | 50-250mm | 50-250mm | 50-250mm | 50-250mm | 50-250mm |
| cutting Area | 510X1250mm | 610X1250mm | 710X1250mm | 810X1250mm | 810X1400mm | 810X1400mm |
| Motor power | 2.2kw | 4kw | 4kw | 5.5kw | 7.5kw | 7.5kw |
| Dimension |
2335X950 X1380mm |
2335X1050 X1400mm |
2380X1150 X1420mm |
2435X1250 X1450mm |
2600X1250 X1500mm |
2600X1250 X1530mm |
| Weight | 1800kg | 2200kg | 2700kg | 3000kg | 4200kg | 4800kg |
| Model | HTA-950T | HTA-960T | HTA-980T | HTA-9100T | HTA-9120T | HTA-9150T |
| cutting Force | 50Tons | 60Tons | 80Tons | 100Tons | 120Tons | 150Tons |
| stroke | 50-250mm | 50-250mm | 50-250mm | 50-250mm | 50-250mm | 50-250mm |
| cutting Area | 710X1250mm | 810X1250mm | 810X1400mm | 810X1400mm | 810X1400mm | 810X1400mm |
| Motor power | 4kw | 5.5kw | 7.5kw | 7.5kw | 11kw | 11kw |
| Dimension |
2030X2720 X1420mm |
2085X3060 X1450mm |
2385X3060 X1500mm |
2380X3060 X1530mm |
2420X3060 X1550mm |
2500X3220 X1600mm |
| Weight | 3000kg | 3500kg | 4800kg | 5500kg | 6000kg | 6500kg |
1. 24 hours online and telephone support; Nomatter anytime, anywhere or any question I will reply you as soon as possible.
2. Exclusive and unique solution can be provided to our customers by well-trained and professional engineers and staffs.
3. Engineers and professional technicians keep seeking the new ways to innovate all of our wheel loaders, which could provide you the most competitive products.
4. Global cooperation with distributors, you can get the most convinent after-sale service. Special discount and protection of sales area provided to your distributor.
5. Your success is our business. We will do our best to provide you the most competitive product with high quality and low price.
FOR MORE DETAILS PLEASE DO NO HESITATE CONTACT WITH US!
