Home > Products > Sponge Foaming Machine > hydraulic 4 column cutting machine for shoe sponge
hydraulic 4 column cutting machine for shoe sponge
- 50 Set / Sets per Month
- guangdong
- T/T Credit Card
You May Like
-
hydraulic sponge scouring pad cutting machine
-
Hydraulic precision four column sponge Epe foam slitting machine
-
precision hydraulic rubber sponge cutting machine
-
Double Side Automatic Feeding Hydraulic Cutting Machine for Blister Package
-
Automatic Die Cutting Machine for PP Blister Packaging
-
Hand operated hydraulic foam sponge cutting machine
Product Details
Brand Name | Houtai | Place of Origin | Guangdong, China | |
Type | Hydraulic Cutting Machine | Certification | CE, ISO9001 | |
Voltage | 220V/380V | |||
Application | plastic,foam,all non-metallic | Rated Power | 7.5kw | |
Condition | New | Power(W) | 7.5kw |
Product Description
Model | HTA-730T | HTA-740T | HTA-750T | HTA-760T | HTA-780T | HTA-7100T |
cutting Force | 30Tons | 40Tons | 50Tons | 60Tons | 80Tons | 100Tons |
stroke | 50-250mm | 50-250mm | 50-250mm | 50-250mm | 50-250mm | 50-250mm |
cutting Area | 510X1250mm | 610X1250mm | 710X1250mm | 810X1250mm | 810X1400mm | 810X1400mm |
Motor power | 2.2kw | 4kw | 4kw | 5.5kw | 7.5kw | 7.5kw |
Dimension | 1985X950 X1380mm | 1985X1050 X1400mm | 2030X1150 X1420mm | 2085X1250 X1450mm | 2385X1250 X1500mm | 2385X1250 X1530mm |
Weight | 1600kg | 2000kg | 2500kg | 2800kg | 4000kg | 4600kg |
Model | HTA-830T | HTA-840T | HTA-850T | HTA-860T | HTA-880T | HTA-8100T |
cutting Force | 30Tons | 40Tons | 50Tons | 60Tons | 80Tons | 100Tons |
stroke | 50-250mm | 50-250mm | 50-250mm | 50-250mm | 50-250mm | 50-250mm |
cutting Area | 510X1250mm | 610X1250mm | 710X1250mm | 810X1250mm | 810X1400mm | 810X1400mm |
Motor power | 2.2kw | 4kw | 4kw | 5.5kw | 7.5kw | 7.5kw |
Dimension | 2335X950 X1380mm | 2335X1050 X1400mm | 2380X1150 X1420mm | 2435X1250 X1450mm | 2600X1250 X1500mm | 2600X1250 X1530mm |
Weight | 1800kg | 2200kg | 2700kg | 3000kg | 4200kg | 4800kg |
Model | HTA-950T | HTA-960T | HTA-980T | HTA-9100T | HTA-9120T | HTA-9150T |
cutting Force | 50Tons | 60Tons | 80Tons | 100Tons | 120Tons | 150Tons |
stroke | 50-250mm | 50-250mm | 50-250mm | 50-250mm | 50-250mm | 50-250mm |
cutting Area | 710X1250mm | 810X1250mm | 810X1400mm | 810X1400mm | 810X1400mm | 810X1400mm |
Motor power | 4kw | 5.5kw | 7.5kw | 7.5kw | 11kw | 11kw |
Dimension | 2030X2720 X1420mm | 2085X3060 X1450mm | 2385X3060 X1500mm | 2380X3060 X1530mm | 2420X3060 X1550mm | 2500X3220 X1600mm |
Weight | 3000kg | 3500kg | 4800kg | 5500kg | 6000kg | 6500kg |
1 | 30T Manual Sponge die cutting machine | https://youtu.be/QhVgBsS0OSg |
2 | Horizontal and vertical slitting machine epe foam plastic cutting machine | https://youtu.be/BJrsh-lzw4Y |
3 | single side plastic sheet die cutting machine with robot arm | https://youtu.be/pIYhox698Z0 |
4 | blister packaging hydraulic cutting machine | https://youtu.be/AJEtDZgaiAI |
5 | All in one full automatic positive and negative multi station machine | https://youtu.be/FykJJhMlo3Q |
6 | High speed Hydraulic Plastic disposable container Cutting Machine | https://youtu.be/ic8GI8cPv0o |
1. 24 hours online and telephone support; Nomatter anytime, anywhere or any question I will reply you as soon as possible.
2. Exclusive and unique solution can be provided to our customers by well-trained and professional engineers and staffs.
3. Engineers and professional technicians keep seeking the new ways to innovate all of our wheel loaders, which could provide you the most competitive products.
4. Global cooperation with distributors, you can get the most convinent after-sale service. Special discount and protection of sales area provided to your distributor.
5. Your success is our business. We will do our best to provide you the most competitive product with high quality and low price.
after-sale service
1.During the first year,all parts are for free,except the consumables and artificially damaged.
2.We will supply operation video for installation,we can also solve your problems through email,photos and some communicate software.we also can provide oversea service.
3.You are also welcomed to our plant for training.We will responsible for the restaurant and meals,the training is for free.
4.We manufacture many embossing machines and hydraulic cutting machines.Such as,four-column plane cutting,gantry,roller cutting.Please find more info on our website.
5.We welcome you come to visit our plant,give us your suggestions,we will try our best to satisfy you.
FOR MORE DETAILS PLEASE DO NO HESITATE CONTACT WITH US!
