Plastic Body Rotary Piston Volumetric Type Cold Water Meter LXH-15P For Apartments
- 1000 Piece / Pieces per Month
- ShenZhen
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
Product Description
Quick Detail:
1.Type name: Volumetric piston water meter
2.Model No.: LXH-15P
3.Standard :ISO 4064 Class C
4.Material: Nylon plastic
5.Feature :Register is sealed with a special liquid
6.Vertical or horizontal installation
Description:
Plastic Body Rotary Piston Volumetric Type Cold Water Meter LXH-15P
Product features:
•Adopting volumetric rotary piston principle of measurement
•Accurate Measurement register separated from water to ensure a clear reading in long-term service
•Material: nylon plastic
•Selected high quality materials for steady & reliable characteristic and good looking
•Plastic meter body adopt the new-style nontoxic plastic material ,with cabinetdesign, this kind of water meter also available for drinking water ,cause of drain hole is a uniquely design to drain off the dirty water .
APPLICATION:
This range of water meter is used to measure the total quantity of cold potable water which consumed in household or a resident unit, passing through the pipeline
Installation requirements:
1. Meter should be installed in vertical or horizontal position with the register face upwards
2. Pipe line must be flushed before installation
3. The meter should be constantly full of water during operation
Main Technical data
Meter Size DN (mm) |
Class
| Qs Overload Flow | Qp Nominal Flow | Qt Transitional Flow | Qmin Min Flow | Starting Flow |
m³/h | L/h | |||||
15 | C | 3 | 1.5 | 22.5 | 15.0 | 5 |
20 | C | 5 | 2.5 | 37.5 | 25 | 7 |
Maximum permissible error:
In the lower zone from Qmin inclusive up to but excluding Qt is ±5%
In the upper zone from Qt inclusive up to and including Qs is ±2%
Working Condition:
Water temperature:0℃≤t≤50℃ (For cold water meter)
Water pressure: ≤10bar
Specifications:
Type | size | L | B | Connection thread | Weight |
LXH-15P | 15 | 115 | 90 | G3/4B | 0.6kg |
LXH-20P | 20 | 190 | 95 | G1B | 0.8kg |
Competitive Advantage:
Reasonable price with good quality
Long time guarantee
100% tested
On time delivery
