cummins speed controller 3037359
1.Description of cummins speed controller 3037359
| Item Name | Controller |
| P/N | 3037359 |
| Gross Weight | 1kg |
| Package Size | 155mm*155mm*60mm |
| Packing | Carton Box |
| Stock | In Stock |
| MOQ | 1 |
| Sample Day | 1-15days |
| Delivery Day | 1-15days |
2.Parameter
| RPM Stability: | <±0.25% |
| Speed Range: | 1KHz ~ 6.5KHz |
| Thermal Stability: | Max ±0.7% |
| IDLE Regulation: | 260 ±20Hz |
| DROOP Regulation: | Minimum 15Hz ±6Hz/ 1 Amp |
| Maximum: 400Hz ±75Hz/ 1 Amp | |
| External Speed Regulation: | ±200Hz (with 1 KΩ connected) |
| AUX Input Sensitivity: | 148Hz / 1V., ±10Hz |
| Impedance: | 1MΩ |
| Working Temp Range: | -40 ~ 85 °C |
| Working Humidity Range: | Maximum 95% |
| Stocking Temp: | -55 ~ 92 °C |
| Shocking: | 20-100HZ 500mm/Sec. |
| INPUT POWER SUPPLY: | |
| Voltage: | 24V |
| Grounding Pole: | Negative pole |
| Power Supply: | 40mA |
| Actuator Continuous Current: | Minimum 1A, Maximum 4.5A |
| Signal: | 2 ~ 120V RMS |
3.More Cummins Controller
| Cummins controller | 3044196 |
| Cummins controller | 3062322 |
| Cummins controller | 3098693 |
| Cummins controller | 3037359 |
| Cummins controller | 4914090 |
| Cummins controller | 4914091 |
| Cummins controller | 3044195 |
| Cummins controller | 3032733 |
| Cummins controller | 3062323 |
| Cummins controller | 4913988 |
| Cummins controller | 3036453 |
| Cummins controller | 3053065 |
| Cummins controller | 3030256 |
4.Photos of Controller 3037359
5.Shopping Guide
Dear customers,welcome to our website.
Because there are thousands of Cummins parts, in order to offer you good service, please kindly tell us the P/N(Part Numer). If you have no P/N, you can aslo tell us the ESN(Engine series Number) which you can find on nameplate of Cummins engine.
6.About US
As the authorized dealer of Chongqing Cummins Engine Company,Ltd., our company is just 1.5 km far away from CCEC. And we mainly supply Cummins N,K and M series diesel engine parts,with the strength of NTA855,KTA19,KTA38,KTA50,MTA11 diesel engine parts.
7.Contact US
Tel: +86-023-65408689
Fax: +86-023-65400559
Add::No1 Da Shuijing, Tong Jiaqiao, Shapingba District, Chongqing, China(Mainland).
