Durable Environmental High Grade Metric O Rings Seals For Lid FDA Factory

Durable Environmental High Grade Metric O Rings Seals For Lid FDA Factory thumbnail-1
Durable Environmental High Grade Metric O Rings Seals For Lid FDA Factory thumbnail-2
Durable Environmental High Grade Metric O Rings Seals For Lid FDA Factory photo-1
Durable Environmental High Grade Metric O Rings Seals For Lid FDA Factory photo-2
US$ 0.01 - 2 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
ZDE
Place of Origin:
China
Model Number:
OR063
Contact Supplier Request Quote Chat Now
Wuxi Previcur Sealing Material Co., Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
5 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name ZDE
Place of Origin China
Model Number OR063
Material Rubber
Style O Ring
Standard or Nonstandard Standard

O-Ring Overview

O-rings are one of the most common types of seals because they're inexpensive, reliable and have simple mounting requirements. Since they are known as one of the most important elements of machine design, o-rings may be used in static applications, where little range of motion is required. O-rings may be used in dynamic applications, like rotating pump shafts and hydraulic cylinder positions, also.


1 - The material selection of o ring

Material: NBR, FKM, EPDM, VMQ, FFKM, FFKM, CR etc.

2 - The hardness selection of o ring
The hardness of o ring is related to the pressure. The normal hardness is 70 shore a and the anti pressure property is 10mpa. 80 shore a is 15mpa. 90 shore a is 25mpa. Other hardness are also available.

3 - The size selection of o ring
Measure the ID and C/S and inform us so we can offer the price to you.




Standard/CS(mm)
 O Ring Size Reference Mould
C92 1.8/2.65/3.55/5.3/7.0 Complete
AS568 1.78/2.62/3.53/5.33/6.99 Complete
JIS2401

P:1.9/2.4/3.5/5.7/8.4

G:3.1/5.7

 Complete
R 1.9/2.7/3.6/5.33/6.99 Complete
DIN3771
 1.8/2.65/3.55/5.3/7.0 Complete
BS4518 1.6/2.4/3.0/5.7/8.4 Complete

Product Tags: metric o rings , o ring seals , rubber seal
