A2f A2fo A2FM A2fe Rexroth Axial Piston Pumps High Pressure Hydraulic Motor and Pump

A2f A2fo A2FM A2fe Rexroth Axial Piston Pumps High Pressure Hydraulic Motor and Pump thumbnail-1
A2f A2fo A2FM A2fe Rexroth Axial Piston Pumps High Pressure Hydraulic Motor and Pump thumbnail-2
A2f A2fo A2FM A2fe Rexroth Axial Piston Pumps High Pressure Hydraulic Motor and Pump thumbnail-3
A2f A2fo A2FM A2fe Rexroth Axial Piston Pumps High Pressure Hydraulic Motor and Pump thumbnail-4
A2f A2fo A2FM A2fe Rexroth Axial Piston Pumps High Pressure Hydraulic Motor and Pump photo-1
A2f A2fo A2FM A2fe Rexroth Axial Piston Pumps High Pressure Hydraulic Motor and Pump photo-2
A2f A2fo A2FM A2fe Rexroth Axial Piston Pumps High Pressure Hydraulic Motor and Pump photo-3
A2f A2fo A2FM A2fe Rexroth Axial Piston Pumps High Pressure Hydraulic Motor and Pump photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Rexroth
Place of Origin:
China
Model Number:
A2F A2FO A2FM A2FE
Contact Supplier Request Quote Chat Now
Guangzhou Ouster Hydraulic Co., Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Rexroth
Place of Origin China
Model Number A2F A2FO A2FM A2FE
Application Other
Power Hydraulic
Usage Oil
Theory Axial Flow Pump
Standard or Nonstandard Standard
Structure Piston Pump
Pressure High Pressure
A2FO 10 12 16 23 28 32 45 56 63 80 90 107 125 160 180 200 250 355 500 710 1000
Displacement Vg cm³ 10.3 12 16 22.9 28.1 32 45.6 56.1 63 80.4 90 106.7 125 160.4 180 200 250 355 500 710 1000
geometric, per revolution
Nominal pressure pnom bar 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 400 350 350 350 350 350
Maximum pressure pmax bar 450 450 450 450 450 450 450 450 450 450 450 450 450 450 450 450 400 400 400 400 400
Maximum speed nnom 1) rpm 3150 3150 3150 2500 2500 2500 2240 2000 2000 1800 1800 1600 1600 1450 1450 1550 1500 1320 1200 1200 950
nmax 2) rpm 6000 6000 6000 4750 4750 4750 4250 3750 3750 3350 3350 3000 3000 2650 2650 2750 1800 1600 1500 1500 1200
Flow at nnom qV l/min 32 38 50 57 70 80 102 112 126 145 162 171 200 233 261 310 375 469 600 852 950
Power at nnomand pnom P kW 22 25 34 38 47 53 68 75 84 96 108 114 133 155 174 207 219 273 350 497 554
Torque 3) at pnom M Nm 66 76 102 146 179 204 290 357 401 512 573 679 796 1021 1146 1273 1393 1978 2785 3955 5570
Rotary stiffness c kNm/rad 0.92 1.25 1.59 2.56 2.93 3.12 4.18 5.94 6.25 8.73 9.14 11.2 11.9 17.4 18.2 57.3 73.1 96.1 144 270 324
Moment of inertia for rotary group JTW kg·m² 0.0004 0.0004 0.0004 0.0012 0.0012 0.0012 0.0024 0.0042 0.0042 0.0072 0.0072 0.0116 0.0116 0.022 0.022 0.0353 0.061 0.102 0.178 0.55 0.55
Maximum angular acceleration ɑ rad/s² 5000 5000 5000 6500 6500 6500 14600 7500 7500 6000 6000 4500 4500 3500 3500 11000 10000 8300 5500 4300 4500
Case volume V l 0.17 0.17 0.17 0.2 0.2 0.2 0.33 0.45 0.45 0.55 0.55 0.8 0.8 1.1 1.1 2.7 2.5 3.5 4.2 8 8
Weight (approx.) m kg 6 6 6 9.5 9.5 9.5 13.5 18 18 23 23 32 32 45 45 66 73 110 155 325 336


Product Tags: Rexroth A2FO , Rexroth A2F , Rexroth A2FM , HYDRAULIC PUMP , HYDRAULIC PUMP PARTS , Rexroth A2FE , HYDRAULIC MOTORS , HIGH PRESSURE PUMP , PISTON PUMP
