IPQ4018 High Power Wireless Router
Model：YN-Q418
Description:
YN-Q418 is a dual-band 11AC Wave-2 wireless Gigabit enterprise router. It has built-in Qualcomm enterprise IPQ4018 / 28 series CPU, large flash and high speed memory, strong data processing capability and support dual frequency concurrency,it is own a reliable all-round quantity and network security, fully assisting the efficient operation of enterprises.
Features:
1. Using Qualcomm 4-core ARM Cortex-A7 IPQ4018/28, cpu frequency 600Mhz
2. Large memory and large storage design to meet different needs
3. Meet the standard of IEEE 802.11n, IEEE 802.11g/b/, 11AC multi-wave-2 IEEE 802.3/3u
4. 1 Gigabit WAN port, 4 Gigabit LAN ports, 1 CONSOLE port, WAN port support POE power supply (12-48V)
5. High power design, 2.4G adopts SKY85309, 5.8G adopts SKY85728
6. Support 11AC, wireless can reach up to 1200M, to meet various application scenarios
7. Support PPPoE, dynamic IP, static IP and other broadband access methods
8. Support 2.0/3.0USB interface for fast shared mobile storage network
9. Industrial grade design, the power supply and network port are support surge 4KV, and electrostatic 8KV which tested in lab
10. Hardware watchdog design, working unobstructe in a whole day
11. Support Open-Wrt system, which is convenient for customers to develop by themselves
Specification
Protocol |
IEEE802.11N/G/B/AC |
||
Chipset |
ARM Cortex-A7 IPQ4018/28,CPU main frequency is 600Mhz |
||
RAM |
Defualt DDR3:256MB, Max. 256MB |
||
FLASH |
Defualt 32MB, Max. 128MB |
||
Wireless Speed Rate |
2.4G:2T2R:300Mbps 5.8G:2T2R:866Mbps |
||
Working Frequency |
2.4Ghz/5.8Ghz |
||
Interface |
Supports 1 10/100/1000M self-adaption WAN with auto flip (Auto MDI/MDIX) Supports 4 10/100M/1000 self-adaption LANs and auto flip (Auto MDI/MDIX) Support 1 CONSOLE port for easy debugging; default is not posted Support 1 2.0 USB Support 1 3.0USB |
||
4G/5G |
4G/5G design 3.0 USB wire, support 4GMINI-PCIE/M2 sharing, support 2/3/4/5G, |
||
Max. Power Consumption |
|||
Dimension |
165X116X19MM(LXWXH) |
||
Working Environment |
Working Temperature: -30 ° C to 75 ° C Storage Temperature: -40 ° C to 100 ° C Working Humidity: 10% to 90% RH does not condense Storage Humidity: 5% to 90% RH does not condense |
||
|
RF(Typical)
|
11A HT20 |
11A HT40 |
11A HT80 |
MCS0/8 23dB±2dB |
MCS0/8 23dB±2dB |
MCS0/8 23dB±2dB |
|
MCS1/9 23dB±2dB |
MCS1/9 23dB±2dB |
MCS1/9 23dB±2dB |
|
MCS2/10 23dB±2dB |
MCS2/10 23dB±2dB |
MCS2/10 23dB±2dB |
|
MCS3/11 22dB±2dB |
MCS3/11 22dB±2dB |
MCS3/11 22dB±2dB |
|
MCS4/12 22dB±2dB |
MCS4/12 22dB±2dB |
MCS4/12 22dB±2dB |
|
MCS5/13 22dB±2dB |
MCS5/13 22dB±2dB |
MCS5/13 22dB±2dB |
|
MCS6/14 21dB±2dB |
MCS6/14 21dB±2dB |
MCS6/14 21dB±2dB |
|
MCS7/15 20dB±2dB |
MCS7/15 20dB±2dB |
MCS7/15 20dB±2dB |
|
|
Sensitivity |
11A HT20 |
11A HT40 |
11A HT80 |
OFDM 6Mbps≤-89 |
MCS0/8≤-83 |
MCS0/8≤-80 |
|
OFDM 9Mbps≤-88 |
MCS1/9≤-80 |
MCS1/9≤-77 |
|
OFDM 12Mbps≤-85 |
MCS2/10≤-78 |
MCS2/10≤-75 |
|
OFDM 18Mbps≤-83 |
MCS3/11≤-75 |
MCS3/11≤-72 |
|
OFDM 24Mbps≤-80 |
MCS4/12≤-71 |
MCS4/12≤-68 |
|
OFDM 36Mbps≤-75 |
MCS5/13≤-67 |
MCS5/13≤-64 |
|
OFDM 48Mbps≤-71 |
MCS6/14≤-66 |
MCS6/14≤-63 |
|
OFDM 54Mbps≤-70 |
MCS7/15≤-65 |
MCS7/15≤-62 |
|
Wireless Security |
Wireless security function switch; 64/128/152 bit WEP encryption; WPA-PSK/WPA2-PSK, WPA/WPA2 security mechanism; WPS fast security settings |
||
Software Features |
Support AP, router, relay, 4G function, etc. Support VPN security tunneling function, Support dynamic routing and static routing Convenient WEB configuration Wireless settings and encryption Support telnet management, easy to use console shell interactive environment Support multiple dialing methods: automatic allocation, specify IP, specify local peer IP, ppoe Support local software upgrade; support configuration export import, and web online update firmware Support operating system Windows XP/7/8/9/10/Linux |
||
