5052 ALUMINUM SHEET SUMMARY:
5052 Aluminum Sheet in H32 temper has very good corrosion resistance to seawater and marine and industrial atmosphere. It also has very good weldability and good cold formability. It is a medium to high strength alloy with a strength slightly higher than 5251 and a medium to high fatigue strength.
5052 ALUMINUM SHEET FEATURES:
5052 aluminum alloy is light in weight, nonmagnetic and non-heat treatable. It has good workability and high fatigue strength with good resistance to correction even in salt water. Besides, it can be anodized to improve correction resistance of the material in corrosive environment. So 5052 aluminum sheet is high suitable for marine applications.
5052 ALUMINUM SHEET CHEMICAL COMPOSITION:
| Elements | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others | Al | ||
| Content | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | 0.1 | - | 0.15 | Remain | ||
5052 ALUMINUM SHEET MECHANICAL PROPERTIES:
| Alloy Temper |
Specified thickness | Tensile strength |
Yield strength |
Elongation | ||||||||
| (MPa) | (MPa) | (%) | ||||||||||
| 5052 HO/H111 | 0.3~0.63mm | 173-213 | min66 | min 15 | ||||||||
| 0.63~1.2mm | min 17 | |||||||||||
| 1.2~6.3mm | min 19 | |||||||||||
| 6.3~50mm | min 18 | |||||||||||
| 5052/H32 or 5052 H22 | 0.4~0.63mm | 214-262 | min159 | min 4 | ||||||||
| 0.63~1.2mm | min 5 | |||||||||||
| 1.2~6.3mm | min 7 | |||||||||||
| 6.3~50mm | min 11 | |||||||||||
| 5052/H34 or 5052 H24 | 0.4~0.63mm | 235-282 | min180 | min 3 | ||||||||
| 0.63~1.2mm | min 4 | |||||||||||
| 1.2~6.3mm | min 6 | |||||||||||
| 6.3~50mm | min 10 | |||||||||||
| 5052/H36 or 5052 H26 | 0.1~0.32mm | 256-303 | min200 | min 2 | ||||||||
| 0.32~0.63mm | min 3 | |||||||||||
| 0.63~4mm | min 4 | |||||||||||
| 5052/H38 or 5052 H28 | 0.15~0.32mm | min269 | min221 | min 2 | ||||||||
| 0.32~0.63mm | min 3 | |||||||||||
| 0.63~3.2mm | min 4 | |||||||||||
5052 ALUMINUM SHEET APPLICATIONS:
5052 aluminum sheet is used for marine, chemical and petrochemical equipment and components.
Treadplate
Boilermaking
Containers
Nameplates
Road Signs
Architectural Paneling
Welded Tubes
Chemical Industry
Irrigation
Desalination units
Pressure Vessels
Rivets
RELEVANT GRADE OF 5052 ALUMINUM SHEET
Relevant grade of 5052 Aluminum Sheet | |
|
|
5052 ALUMINUM SHEET PACKING:
5052 Aluminum Sheet of packaging meet the export standard. Plastic film and brown paper can be covered at customers’ need. wooden case or wooden pallet is adopted to protect products from damage during the delivery.
As a China-based 18 years 5052 aluminum sheet manufacturer and supplier, we at Huawei also produce aluminum slit coil, aluminum strip, coated aluminum coil, aluminum plate, anodising aluminum sheet, embossed aluminum sheet, etc. For more detailed information, please continue browsing our website or feel free to contact us directly. -
