3003 ALUMINUM SHEET FEATURES:
Alloy:3003
Temper: H14, H16, H18, H22, H24, H26, O
Thickness(mm):0.25-10
Width(mm):100-2600
3003 aluminum sheet is anticorrosive and its production technology is good.
The main ingredient in it is manganese element and the content is between 1.0% and 1.5%.
3003 ALUMINUM SHEET CHEMICAL COMPOSITION:
| Alloy No. | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others | Al | ||
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | 0 | 0 | 0.10 | 0 | 0.20 | REMAIN | ||
3003 ALUMINUM SHEET PROPERTIES BY TEMPER (TYPICAL)
| Products | Type | Temper | Thickness(mm) | Width(mm) | Length（mm） | |||||||
| 3003 Aluminum sheet | Painted, Bare, Mill Finish Tread plate |
O H14 H16 H18 |
0.2-4.5 | 100-2600 | 500-16000 | |||||||
| 0.02-0.055 | 100-1600 | Coil | ||||||||||
| 0.8-7.0 | 100-2600 | 500-16000 | ||||||||||
3003 ALUMINUM SHEET MECHANICAL PROPERTIES:
| Material | Condition | Tensile Strength (ksi min) | Yield Strength (ksi min) | Elongation % in 2" 0.064 sheet | Min 90° Cold Bend Radius for 0.064" Thick |
| 3003-0 sheet 0.064" thick | 3003-0 | 14-19 | 5 | 25 | 0 |
| 3003-H12 sheet 0.064" thick | 3003-H12 | 17-23 | 12 | 6 | 0 |
| 3003-H14 sheet 0.064" thick | 3003-H14 | 20-26 | 17 | 5 | 0 |
| 3003-H16 sheet 0.064" thick | 3003-H16 | 24-30 | 21 | 4 | 1/2 - 1 1/2 T |
| 3003- sheet 0.064" thick | 3003-H18 | 27 min | 24 | 4 | 1 1/2 -3T |
RELEVANT GRADE OF 3003 ALUMINUM SHEET:
Relevant grade of 3003 Aluminum Sheet | |
|
|
3003 ALUMINUM SHEET APPLICATION:
3003 Aluminum Sheet can be used for sheet metal works, spinning, drawing, fuel tanks, tapping, forming and a variety of other applications. As a 3003 alloy, H14 aluminum plates can be formed easily. Debossing or embossing an alloy of this temper can typically be done without cracking or straining the metal.
As a China-based 1000 aluminum sheet manufacturer and supplier, we at Huawei also produce aluminium slit coil, aluminum strip, coated aluminum coil, aluminum plate, anodising aluminum sheet, embossed aluminum sheet, etc. For more detailed information, please continue browsing our website or feel free to contact us directly.
As a China-based 1000 aluminum sheet manufacturer and supplier, we at Huawei also produce aluminium slit coil, aluminum strip, coated aluminum coil, aluminum plate, anodising aluminum sheet, embossed aluminum sheet, etc. For more detailed information, please continue browsing our website or feel free to contact us directly.
As a China-based 1000 aluminum sheet manufacturer and supplier, we at Huawei also produce aluminium slit coil, aluminum strip, coated aluminum coil, aluminum plate, anodising aluminum sheet, embossed aluminum sheet, etc. For more detailed information, please continue browsing our website or feel free to contact us directly.
as a China-based 3003 aluminum sheet manufacturer and supplier, we at Huawei also produce aluminum slit coil, aluminum strip, coated aluminum coil, aluminum plate, anodising aluminum sheet, embossed aluminum sheet, etc. For more detailed information, please continue browsing our website or feel free to contact us directly.
3003 ALUMINUM SHEET PACKING:
Factory profit off 3003 aluminum sheet of henan huawei Aluminum meet the export standard. Plastic film and brown paper can be covered at customers'need. What's more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.
As a China-based 3003 aluminum sheet manufacturer and supplier, we at Huawei also produce aluminum slit coil, aluminum strip, coated aluminum coil, aluminum plate, anodising aluminum sheet, embossed aluminum sheet, etc. For more detailed information, please continue browsing our website or feel free to contact us directly.
