CNC Knife Cutting Machine for Leather
1. Features of CNC knife cutting machine for leather :
This is the newest product we designed for shoes,luggage,furniture industry and it can provide economic cutting solution for them.It is mainly for cutting fabric ,leather for small batch production.Due to its high-speed oscillating blade can also cut other material like KT board,cardboard,carbon fiber prepreg etc。It is also used in other industry like automotive,aircraft,advertisement etc.
(1). The platform detection device regulates the knife pressure automatically, enabling a level platform and perfect cutting.
(2). The leather digital cutting machine can induce draft separately and easily cuts small pieces.
(3). The anti-collision and the built-in auto-sensing devices ensure the security of leather digital cutting machine with good quality.
(4). High efficiency can be realized without making a high-cost knife model.
(5). The CNC auto feeding Vibrating Knife Cutting Machine for leather and fabric is designed for production with small quantities and can save on costs while maintaining speed and accuracy.
Besides leather, machines with oscillating knife that cut leather can cut many types of foam,such as closed cell foam,rubber foam,foamex, foam core,KT board,EPE foam,PVC foam,etc.
It's widely used for garment industry,packaging protection,advertising
display,termal insulation,model&mock up making,puzzle and pattern cutting,etc.
Cutting video: https://youtu.be/mtzgUztpTMw
4.Technical parameter of the machine:
| Model (customizable) | 1625 | 1825 | 2125 |
| Working area | 1600*2500 mm | 1800*2500 mm | 2100*2500 mm |
| Rated power | 11 KW | ||
| Fixed mode | Vacuum suction table(auto feeding table for option) | ||
| Multifunctional head | Swiss imported knife: oscillating knife, rotary knife, kisscut, punching, V-cut, milling cutter | ||
| Tool configuration | Multiple cutting knives | ||
| Safety device | Using infrared sensors,responsive,safe and reliable | ||
| Translational velocity | 800-1200 mm/s | ||
| Cutting speed | 200-1000 mm/s (according to different cutting materials) | ||
| Cutting thickness | 0-22 mm(according to different cutting materials) | ||
| Cutting materials | All kinds of flexible materials, sponge composite leather, fabric, PVC, glass fiber, silicon, rubber, carbon fiber, cardboard, KT board, PE, carpet, gasket, ABS and so on. | ||
| Repeated accuracy | ≤0.1 mm | ||
| Capacity | 2 GB | ||
| Transmission system | Imported (Digital servo motor, linear guide, synchronous belt, ball screw) | ||
| Introduction system | HP-GL compatible format | ||
| Voltage | 220 V/380 V/50 Hz/60 Hz | ||
| Other configuration | Servo motor, Germany imported conveyor belt, vacuum table, auto feeding,Taiwan Hiwin rail,9 kw vacuum pump | ||
5.Why choose CNC knife cutting machine for leather:
6.Our service
1). We will supply with the machine operation manual in English version for installing and operation.
2). Machine has been adjusted before delivery, operation disk was included
3). Supply after service 24 hours, customer can contact me at any time by email or calling
8. Why did they choose China AOYOO ?
1. We are a professional CNC leather cutting machine supplier for many years experiences in china,offering all kinds of various laser and CNC equipments.
2. International quality certificate:CE,FDA,CCC,ISO9001
3. 24 hours technician professional and timely after-sale service.
4. We guarantee the machine for 1 years and the laser's fan and other important parts can used long life.
5. This machine can engraving and cutting.
6. According to your different requirements, AOYOO leather digital cutting machine can be equipped with multi-functional, combined cutting tools.It is easy for uesrs to learn and operate.
Our official website:
Please feel free to contact us, we will reply within 24h!About CNC knife cutting machine for leather we want to know:
1.What materials do you need to process?
2.The size and thickness of the material?
