Crawler Pneumatic Rock Drilling Rig Water Well Drilling Machine Fast Speed and Deep Drilling
US$ 4000 - 7500
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huaxia Master
Place of Origin:
China
Model Number:
FY 260
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
7 days
Related Products
-
Crawler Pneumatic Water Well Drilling Rig Drilling With Large Diameter and Deep Drilling Footage Flexible and EfficientUS$ 4000 - 6000MOQ: 1 Set -
Huaxia Masetr Sells 400 m Pneumatic Well Drilling Rig, Tracked Large Well Drilling MachineUS$ 4000 - 6000MOQ: 1 Set
-
Water Well Drilling Machine Powered by Compressor, Tracked Large Diameter Pneumatic Drilling MachineUS$ 4000 - 6000MOQ: 1 Set
-
Power Grinding Disc Drilling Machine, Large Diameter Well Drilling Rig Easy to DisassembleUS$ 4000 - 6000MOQ: 1 Set
-
Kohler Engine Vertical Backpack Portable Core Drilling Rig With Diamond BitUS$ 4000 - 6000MOQ: 1 Set
Brand Name
Huaxia Master
Place of Origin
China
Model Number
FY 260
Type
Other, Impact Drilling Rig
Certification
ISO-9001
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
1 Year
Weight
6.2 t
Dimension(L*W*H)
3900*1950*2550 mm
Power Type
Diesel
Voltage
380 V
Usage
Water Well
Condition
New
Power(W)
85 KW
1. The applications of FY260 crawler pneumatic drilling rig
· civil engineering drilling
· geothermal drilling,
· drilling with large diameter
· deep drilling footage
· fast, flexible and efficient.
2. The specifications of FY260 crawler pneumatic drilling rig
Model |
FY260 |
|
Gross weight |
t |
6.2 |
External dimension |
mm |
3900*1950*2550 |
Aperture |
mm |
140-325 |
Drilling depth |
m |
260 |
Feed stroke |
mm |
3000 |
Travel speed |
km/h |
2.5 |
Grade ability |
max. |
30° |
Rising height from ground |
mm |
250 |
Wind pressure |
mpa |
1.7-3.0 |
Air consumption |
m³/min |
17-35 |
Engine power |
kw |
85 |
Rotary speed |
rpm |
40-70 |
Rotation torque |
n.m |
7000-9000 |
