Home > Products > Brass Oil sight glass > brass oil level sight glasses OEM and ODM service G 3/4 G1/2 G1/4
brass oil level sight glasses OEM and ODM service G 3/4 G1/2 G1/4
- 100000 Piece / Pieces per Month
- Ningbo port
- T/T
- 45 days
- brass liquid level glass sights for truck radiators surge tanks NPT/BSP thread
- brass oil level glass sights for truck radiators NPT pipe thread 1 inch
- brass oil level glass sight for air compressors,blowers,NPT thread supplier
- male NPT 1 inch stainless steel 304 oil level sight glass liquid level gauge
- Aluminum die casting fir fighting flammable and explosive detector aluminum housing case
- stainless steel 304 oil level sight glass male bsp thread G3/4\" G1\"
Product Details
Brand Name: | www.grandmfgcn.com | Place of Origin: | China | Model Number: | GM |
Material: | Other, BRASS | Type: | Sight Glass | Shape: | Equal |
Technics: | Other, BRASS BAR | Connection: | Male | Head Code: | Hexagon |
Product Description
Material Body: Aluminum 6061 T6/Aluminum 6063
O-Ring: Viton,FKM,NBR, Aramid gasket and Copper seal
Glass Thickness: 2mm to 5 mm
Reflectors: Stainless Steel 304 Reflector
(Any type you can chose with reflector or without Reflector, You also can add float ball.)
Glass Type: Natural Glass,Tempered Glass and Borosilicate Glass
Resist Tempreature Range:-30'C to 120'C
Pressure Range: 5-10 Bar(0.5MPa to 1 MPa).
Thread type:NPT,NPTF,UNC,UNF,Metric and BSP(G thread)
Size: Below you will get the size you wanted.Another size is okay.OEM are welcome.
Usage: Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission.
item | aluminum sight glasses |
material body | Aluminum 6061 T6/Aluminum 6063 |
O-Ring | Viton,FKM,NBR, Aramid gasket and Copper seal |
window | Natural Glass,Tempered Glass and Borosilicate Glass |
Glass Thickness | 2mm to 5 mm |
Reflectors | Stainless Steel 304 Reflector (Any type you can chose with reflector or without Reflector, You also can add float ball.) |
Resist Tempreature Range | .-30'C TO 120'C |
Pressure Range | 5-10 Bar(0.5MPa to 1 MPa). |
Thread type | UNC,UNF,Metric and BSP(G thread) |
size | Below you will get the size you wanted.Another size is okay. OEM are welcome. |
Usage | Pump,Oil Receivers,Gearboxes,Speed Reducer,Compressor and Power Transimission. |
