Home > Manufacturing & Processing Machinery > Drilling Rig > Mine Drilling Rig > Small Ground Drilling Rig XY-150 Water Well Drilling Machine/high Speed 100meters Drilling Equipment From HuaxiaMaster

Small Ground Drilling Rig XY-150 Water Well Drilling Machine/high Speed 100meters Drilling Equipment From HuaxiaMaster

Small Ground Drilling Rig XY-150 Water Well Drilling Machine/high Speed 100meters Drilling Equipment From HuaxiaMaster photo-1
Small Ground Drilling Rig XY-150 Water Well Drilling Machine/high Speed 100meters Drilling Equipment From HuaxiaMaster photo-2
Small Ground Drilling Rig XY-150 Water Well Drilling Machine/high Speed 100meters Drilling Equipment From HuaxiaMaster photo-3
Small Ground Drilling Rig XY-150 Water Well Drilling Machine/high Speed 100meters Drilling Equipment From HuaxiaMaster photo-4
Small Ground Drilling Rig XY-150 Water Well Drilling Machine/high Speed 100meters Drilling Equipment From HuaxiaMaster photo-5
US$ 5100 - 5200 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
huaxiamaster
Place of Origin:
China
Model Number:
XY-150
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
5 days
Brand Name huaxiamaster
Place of Origin China
Model Number XY-150
Type Rotary Drilling Rig
Certification ISO9001
After-sales Service Provided Engineers available to service machinery overseas
Warranty 6 months
Power Type Diesel
Usage Water Well
Condition New
Power(W) 11KW

XY-150 hydraulic water well drilling rig

1.Applications of XY-150 hydraulic water well drilling rig

  • geological survey

  • geophysical exploration

  • road and high-rise building foundation exploration

  • water wells

  • blasting holes and other drilling projects

    2. Parameters of XY-150 hydraulic water well drilling rig

Drilling depth(m)

150

Maximum opening diametermm

219

The final hole diameter(mm

73

Rod diametermm

42/50

Spindle speed (r/min)

140/295/470/790/1010

Spindle strokemm

450

Hoisting capacity (kn)

14

Steel wire diametermm

9.3

Maximum pressure (mpa)

1.2

Working pressure (mpa)

0.7

displacementl/min

150

Hydraulic pump pressure (mpa)

1.2

Hydraulic pump rotation speed (r/min)

1800

Matched driving power (diesel engine and motor)

S1105 diesel engine and 11kw motor



Product Tags: geophysical exploration , blasting holes and other drilling projects , water wells
