XY-150 Hydraulic Core Drilling Rig From HuaxiaMaster

Name: XY-150 Hydraulic Core Drilling Rig From HuaxiaMaster
Brand: HuaxiaMaster
SKU: 161276203

US$ 5100 - 5200 MOQ: 1 Set

Key Specifications

Brand Name:

HuaxiaMaster

Place of Origin:

China

Model Number:

XY-150

Shandong Huaxia Master Machinery Co.,Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

7 days

Brand Name HuaxiaMaster

Place of Origin China

Model Number XY-150

Type Rotary Drilling Rig

Certification ISO9001

After-sales Service Provided Overseas service center available

Warranty Six months

Weight 610kg

Power Type Electric

Voltage 380V/220V

Usage Ore

Condition New

Power(W) 14.7KW

XY-150 hydraulic core drilling rig

1. Applications of XY-150 hydraulic core drilling rig

· geological survey

· geophysical exploration

· road and high-rise building foundation exploration

· water wells

· blasting holes and other drilling projects

2. Parameters of XY-150 hydraulic core drilling rig

Drilling depth(m)	150
Maximum opening diameter（mm）	219
The final hole diameter（mm）	73
Rod diameter（mm）	42/50
Spindle speed (r/min)	140/295/470/790/1010
Spindle stroke（mm）	450
Hoisting capacity (kn)	14
Steel wire diameter（mm）	9.3
Maximum pressure (mpa)	1.2
Working pressure (mpa)	0.7
displacement（l/min）	150
Hydraulic pump pressure (mpa)	1.2
Hydraulic pump rotation speed (r/min)	1800
Matched driving power (diesel engine and motor)	S1105 diesel engine and 11kw motor
