Automatic Enameled Wire Transformer Coil Winding Machine

Automatic Enameled Wire Transformer Coil Winding Machine

CLICK HERE to check videos:

https://youtu.be/qCFluhINhQU

Application

It is a very popular machine which can wind a wide range of HV coils for distribution transformers using round and rectangular conductors.

Composition

winding host

automatic wire guide traversing mechanism

insulation layer decoiler

round wire and flat wire decoiler with tension control

PLC control

Operation touch screen

Pneumatic system and foot pedal

technical parameter

main components brand

Accessories

Equipment Feature

1.flat wire decoiler with tension control offer precise variable air actuated tension and they reduce spool over spin when winding stops.tension force can be regulated from the operator control station.

2.Wire tension system for tension medium size round wire.

By utilizing a pneumatic dancer,the wire tension remains consistent and the wind quality uniform.

The tension head is mounted to a frame that provides for paying the wire off over the end of the supply roll or out of a barrel

3.Automatic insulation layer feeder.

Jinan Shuohao Machinery Co., Ltd is factory specializing in design,manufacture,train for transformer making equipment .Main products include transformer coil winding machine,foil winding machine,busbar bending cutting punching machine,silicon core assembly table,amorphous core and coil assembly table,insulation paper folding machine,corrugated paper making machine,core coil reshaping machine.

Those products has been exported to Thailand,France,Vietnam,Myanmar,Pakistan,Australia,

Turkey,India,Russia and so on.Has more than 20 patents,Certificate of CE,ISO9001:2008

To satisfy customer after sales service,professional team responsible for training,guarantee customer products quality.Welcome old and new customer visit our factory.
