4FT Plywood Woodworking Hydraulic Wood Log Rounder Debarker Machine With Waste Chipper
US$ 5000 - 8000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
METRO MACH/ LEAD TOP
Place of Origin:
China
Model Number:
RBDX1400
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
30 days
Related Products
-
4FT Plywood Woodworking Wood Log Rounding Debarker MachineUS$ 5000 - 8000MOQ: 1 Set -
8FT Plywood Woodworking Wood Log Rounding Debarker MachineUS$ 5000 - 8000MOQ: 1 Set
-
Woodworking Automatic Wood Log Rotary Debarker Machine With Wood ChipperUS$ 5000 - 8000MOQ: 1 Set
-
Hydraulic Woodworking Plywood Log Rounding Debarker MachineUS$ 5000 - 8000MOQ: 1 Set
-
Woodworking Glue Mixer Machine for Making PlywoodUS$ 200 - 1500MOQ: 1 Set
Brand Name
METRO MACH/ LEAD TOP
Place of Origin
China
Model Number
RBDX1400
After-sales Service Provided
Engineers available to service machinery overseas
Weight
3500kg
Dimension(L*W*H)
4400*2000*1500mm
Voltage
380/415V
Certification
1 Year
Condition
New
Power(W)
40.5kw
Spindle Speed
60 m /min
Wood Length Range
970-1400mm
Wood Diameter Range
Max 600mm
Hydraulic 4FT Wood Log Rounding Debarker Machine with Chipper
1. Fearures
Log rounding debarker is used for peeling off the log skin and make the raw log to be round,after debarking it will be easy for the peeling lathes to peel and the veneer thickness will be even without big variation,also can increase the peeling lathes working life.One set debarker can work with two sets of peeling lathes, it can save labor.
2. Technical Parameters
| DESCRIPTION | UNIT | PARAMETERS |
| Length of peeler log | mm | 970mm-1270mm-1400MM |
| Diameter of peeler log | mm | Maximum 550mm-Core 50mm |
| Rotary cutting thickness range | mm | 1mm-4.0mm |
| Linear speed of host machine | m/min | 60m |
| Main motor power Auxiliary motor power |
KW | 11KW+7.5KW Feeding 5.5KW Hydraulic pump 5.5Kw(Air cooling device) Waste chipper 11KW(Optional) |
| Reducer type selection | #350 Heavy Model | |
| Rollers specification | mm | Ø150mm x 1500mm(Harden chroming thicker) |
| Machine weight | Kgs | 3500Kgs |
3. More Pictures
