Hospital Electric Tower Crane Arm Surgery Medical Pendant Ecoh056
- 5000 Set / Sets per Month
- Shanghai
- T/T L/C
Product Details
Brand Name: | MEDECO | Place of Origin: | China | Model Number: | Surgery Medical Pendant ECOH056 |
Type: | Other |
Product Description
Electric single-arm Pendant(Model ECOH056)
ECOH056 Electric Double-arm pendant
Integrated platform for surgical and monitoring instruments
330° free space orientation,easy adjustment of up-and-down
Medical gas supply, power supply, and information terminals in one set
Double turning arms, wider movement ranges
Suitable for needs of surgical instruments and equipments locations
1. Apply in operating room, endoscope room, anesthesia room and hospital wards so on
2. Is available in single and double arm configurations. Each joint has a ratation range up to ≤350 degree.
3.Ceiling-mounted installation
4. Pendant column can be designed to accommodate a large variety of medical gas outlets and electrical device.
5. One arm, can rotation, rotation angle≤350 degree.
6. High-strength aluminium alloy, wearwell reduce your cost
7. Pendant color: Blue, red and so on
8. Medical gas outlet optional German / British /America/Japanese/ French /Chinese standards.
Detailed Technical Parameter | |||||
1 . apply in operating room ,endoscope room ,anesthesia room and hospital wards so on 2. is available in single and double arm configurations .Each joint has a ratation range up to ≤350 degree. 3. ceiling-mounted installation 4.pendant column can be designed to accommodate a large variety of medical gas outlets and electrical device. 5. one arm, can rotation, rotation angle≤350 degree. 6. high-strength aluminium alloy,wearwell reduce your cost 7. Pendant color :blue ,red and so on dical gas outlet optional German / British /America/Japanese/ French /Chinese standards. 9. can horizontal rotation ,can lift ,lift length 400-600mm | |||||
Standard Configuration | |||||
Item | Parameter | Mark | |||
pendant material | used high-strength aluminum alloy ,modular design ,surface electrostatic powder painting,prevent corrosive ,easy to clean | low maintenance,never rust | |||
brake way | mechanical friction brake,to make sure without drifting and easy to stop,insure safe | the pneumatic brake is optional | |||
rotary arm length | single:1000mm | double:800+800mm | the arm length is optional | ||
Rotary radius | ≥650mm | ||||
loading capability | single arm :≥250kg | double arm:≥220kg | |||
shelf loading | ≥60kg | ||||
shelf | 2pcs (with prevention of collision system) | quantity is optional ,height can adjust | |||
medical gas outs | O2*1,Air*1,Vac*1 (for surgical) | for endoscopy | |||
O2*1,Air*1,Vac*1,CO2*1 | |||||
power socket | multifunctional 3pin 8pcs (220V 10 A,Legrand) | style and quantity is optional (Max 16pcs ),max quantity according to the style | |||
net socket | RJ45 1pcs | quantity is optional | |||
extension arm | 1pcs | quantity is optional | |||
basket (S/S) | 1pcs | ||||
drawer | 1pcs | automatic suction type,insures swivel safe | |||
column length | 800mm | length is optional | |||
box pendant head length | 560mm | length is optional | |||
level degrees rotation | ≤350 º | ||||
electrical lift length | 400-600mm |
