Home > Products > Medical Pedant > Hospital Surgical Tower Crane Arm Medical Pendent Bridge Model Ecoh059
Hospital Surgical Tower Crane Arm Medical Pendent Bridge Model Ecoh059
USD $1 - $999
/ Set
1 Set(Min.Order)
- 5000 Set / Sets per Month
- Shanghai
- T/T L/C
You May Like
Product Details
Brand Name: | MEDECO | Place of Origin: | China | Model Number: | Ecoh059 |
Type: | Other |
Product Description
Medical Equipment Tower Crane Arm Medical Pendent bridge Model ECOH059
Integrated platform for surgical and monitoring instruments medical gas supply,power supply,and information terminals in one set Medical Pendent bridge (Model ECOH059) free movement,convenient adjustment suitable for needs of surgical instruments and equipments locations in ICU
Detailed Technical Parameter | ||||||
1. apply in operating room ,endoscope room ,anesthesia room and hospital wards so on 2. is available in single and double arm configurations .Each joint has a ratation range up to ≤350 degree. 3. Ceiling-mounted installation 4. Pendant column can be custom designed to accommodate a large variety of medical gas outlets and electrical device. 5. One arm, can rotation, rotation angle≤350 degree. 6. high-strength aluminium alloy,warewell reduce your cost 7. Pendant color :blue ,red and so on 8.Medical gas outlet optional German / British /America/Japanese/ French /Chinese standards. 9. can horizontal rotation ,cannot lift | ||||||
Standard Configuration | ||||||
Item | Parameter | Mark | ||||
pendant material | used high-strength aluminum alloy ,modular design ,surface electrostatic powder painting,prevent corrosive ,easy to clean | low maintenance,never rust | ||||
brake way | mechanical friction brake, | the pneumatic brake is optional,to make sure without drifting and easy to stop,insure safe | ||||
rotary arm length | single arm 1000mm | double arm 800+800mm | the arm length is optional | |||
Rotary radius | ≥650mm | |||||
loading capability | single arm EX- 50≥180kg single arm EX-60≥250kg | double arm EX-50≥150kg double arm EX-60≥220kg | ||||
shelf loading | ≥60kg | |||||
equipment shelf | 2pcs (with prevention of collision system) | quantity and height is optional | ||||
medical gas outs | O2*1,Air*1,Vac*1 (for surgical) | for endoscopy | for anaesthesia | |||
O2*1,Air*1,Vac*1,CO2*1 | O2*1,Air*1,Vac*1,CO2*1,AGSS*1 | |||||
power socket | multifunctional 3pin 8pcs (220V 10 A,Legrand) | style and quantity is optional | ||||
net socket | RJ45 1pcs | quantity is optional | ||||
extension arm | 1pcs | quantity is optional | ||||
basket (S/S) | 1pcs | |||||
drawer | 1pcs | automatic suction type | ||||
column length | 800mm | length is optional | ||||
box pendant head length | 650mm | length is optional | ||||
level degrees rotation | ≤350 º | |||||
pendant body rotation | ≤350 º |
