Ploymer Lithium Battery With IEC/EN62133, KC, UL, UN, CE, CB, PSE Certificates Best Quality Lipo Battery

Ploymer Lithium Battery With IEC/EN62133, KC, UL, UN, CE, CB, PSE Certificates Best Quality Lipo Battery thumbnail-1
Ploymer Lithium Battery With IEC/EN62133, KC, UL, UN, CE, CB, PSE Certificates Best Quality Lipo Battery thumbnail-2
Ploymer Lithium Battery With IEC/EN62133, KC, UL, UN, CE, CB, PSE Certificates Best Quality Lipo Battery thumbnail-3
Ploymer Lithium Battery With IEC/EN62133, KC, UL, UN, CE, CB, PSE Certificates Best Quality Lipo Battery thumbnail-4
Ploymer Lithium Battery With IEC/EN62133, KC, UL, UN, CE, CB, PSE Certificates Best Quality Lipo Battery thumbnail-5
Ploymer Lithium Battery With IEC/EN62133, KC, UL, UN, CE, CB, PSE Certificates Best Quality Lipo Battery photo-1
Ploymer Lithium Battery With IEC/EN62133, KC, UL, UN, CE, CB, PSE Certificates Best Quality Lipo Battery photo-2
Ploymer Lithium Battery With IEC/EN62133, KC, UL, UN, CE, CB, PSE Certificates Best Quality Lipo Battery photo-3
Ploymer Lithium Battery With IEC/EN62133, KC, UL, UN, CE, CB, PSE Certificates Best Quality Lipo Battery photo-4
Ploymer Lithium Battery With IEC/EN62133, KC, UL, UN, CE, CB, PSE Certificates Best Quality Lipo Battery photo-5
Negotiable MOQ: 200 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
FELLO
Place of Origin:
China
Model Number:
FT502333P
Contact Supplier Request Quote Chat Now
Fello Tech Co;LIMITED
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name FELLO
Place of Origin China
Model Number FT502333P
Size Other, 5.0X23X33mm
Nominal Capacity 380mAh
Nominal Voltage Other, 3.7V

Ploymer lithium battery with IEC/EN62133, KC, UL, UN, CE, CB, PSE certificates best quality lipo battery

S/N

Details

Parameters

Remarks

1

Rated voltage

3.7V

2

Rated capacity

400mAh

discharge with 0.2C to 2.75V after fully charge within 1h, measuring the discharge time

3

Limited charge voltage

4.20V

4

Internal resistance

≤180mΩ

5

charge mode

C.C/C.V.

6

Standard charge current

80mA

0.2C

7

Max Charge Current

400mA

1C

8

Standard discharge current

80mA

0.2C

9

Max discharge current

Continuous：400mA

1C

10

Working temperature

charging

0~45℃

discharging

-10~60℃

11

Storage temperature

1 Month

-10~45℃

Charge to 40%~50% of capacity when storage

6 months

-10~30℃

12

Storage humidity

45%~75％

relative humidity

13

Weight

Approx 9g

14

Cycle life

300 times

capacity≥80%

Rated voltage: 3.7V
Rated capacity:380mAh
Limited charge voltage: 4.20V
Standard charge current : 80mA
Max charge current :380mA
Max discharge current continous :400mA

  • Cycle lifespan: 500 times

  • Working temperatures:

    • Charge: 0-45°C, 45-85% RH

  • Discharge: -20-60°C, 45-85% RH

    • Storage temperatures:

    • One month: -10-45°C, 45-85% RH

    • Three months: -10-35°C, 45-85% RH

  • One year: -20-25°C, 45-85% RH

  • Protection functions: over-charge, over-discharge, overload, short-circuit

  • Features:

    • High-energy density

    • High-single cell voltage

    • Lightweight

    • Small size

    • High-security

    • Stable operating voltage

    • Wide operating temperature range

    • Low self-discharge rate

  • Main applications:

    • Communications equipment: mobile phones, PHS phones, Bluetooth cellphones, walkie-talkie

    • Information equipment: laptop computers, PDA, portable fax machines, printers

    • Audio-visual equipment: digital cameras, camcorders, portable DVD, VCD

    • Others: electric bicycles, miner's lamps

  • Company overview:

    • Fello Tech Co., Ltd is an experienced manufacturer of batteries specialized in the production of rechargeable and primary lithium batteries, including aluminum case lithium ion batteries, li-polymer batteries, LiFePO4 batteries, LiSOCL2 battery, LiMnO2 battery and custom-designed battery packs, mobile phone battery and power bank

    • We welcome OEM and ODM orders and we sincerely hope to work with you hand in hand to create a prosperous future

    • Experienced staff

    • Reasonable price

    • Product performance

    • Quality approvals

    • Small orders accepted


    • Warning:

    • Do not disassemble, dispose in fire, heat or short circuit

    • Do not insert batteries with the (+) and (-) reversed

    • Do not mix fresh batteries with used batteries

    • Do not submerge the battery in water
