Fiber Array
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Fiberpark or OEM
Place of Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
Fiberpark or OEM
Place of Origin
China
Fiber Arrays are fabricated with high precision V-groove substrate by FP unique assembly/polish process to get an excellent accuracy of fiber core position and perfect quality of polish surface. FP provides high quality Fiber Array to meet customers various demands with low insertion loss, high return loss and compact dimension. FP Provide FA in configuration 1-64ch
Typical core pitch tolarence within ±0.5μm. PYREX, TENPAX, QUARTZ, SILICON based material of V-Groove are used.
Features
Low Insertion Loss
Window stripped process available
High Stability and reliability
Applications
Splitter Application
AWG Applicatoin
MEMS Products
Lan-WDM Products
| Parameters | Unit | Specifications | Customized | |||||
| 1 | Material | --- | PYREX, TEMPAX, QUARTZ, SILICON | --- | ||||
| 2 | Core Pitch | um | 250 for 1, 2, 4, 8,12CH 127 for 16, 24, 32, 48,64, 128CH |
Customized | ||||
| 3 | Core Pitch Tolerance | um | ±0.5 for 1-8CH, ±0.7 for 12-64CH ±1.0 for 128CH |
Customized | ||||
| 4 | Polish Angle | ° | 0, 8 | Customized | ||||
| 5 | Fiber Type | --- | G.652, G.657, MM | Customized | ||||
| 6 | Ribbon Type | --- | 1F, 4F, 8F, 12F | --- | ||||
| 7 | Operation Temperature | ºC | -40 to 85 | --- | ||||
| 8 | Storage Temperature | ºC | -40 to 85 | --- | ||||
| 9 | Typical Dimensions-1CH | W*L*H | 2.5*8*2.5 | Customized | ||||
| Typical Dimensions-2CH | W*L*H | 2.5*8*2.5 | Customized | |||||
| Typical Dimensions-4CH | W*L*H | 2.5*8*2.5 | Customized | |||||
| Typical Dimensions-8CH | W*L*H | 2.5*10*2.5 | Customized | |||||
| Typical Dimensions-12CH | W*L*H | 3.2*10*2.5 | Customized | |||||
| Typical Dimensions-16CH | W*L*H | 3.2*10*2.5 | Customized | |||||
| Typical Dimensions-24CH | W*L*H | 5.7*12*2.5 | Customized | |||||
| Typical Dimensions-32CH | W*L*H | 5.7*12*2.5 | Customized | |||||
| Typical Dimensions-48CH | W*L*H | 9*12*2.5 | Customized | |||||
| Typical Dimensions-64CH | W*L*H | 10*12*2.5 | Customized | |||||
| Typical Dimensions-128CH | W*L*H | 17.8*15*2.5 | Customized | |||||
