BSJ-E600A 2.4G directional active RFID reader

Ø  Anti-interference ability is strong, is not affected by the radio waves；

Ø  Accuracy of identification: up to 99.999999%；

Ø  Advanced anti-collision capacity: identify more than 2000 tags simultaneously(now 500 tags identify at one time has been tested)；

Ø  Good directivity (60 degrees included Angle), no lane interference (no interference between 1 in 1 and 1 out)；

Ø  Read-write range: 0-150m adjustable (user software adjustment)；

Ø  Easy to use and support multiple communication modes (RS232, RS485, WG26,WIFI(Optional),TCP/IP(Optional),GPRS(Optional))；

Ø  Type of the reading tag: read only active electronic tag ，type of BSJ601；

Ø  work frequency:2400－2500MHz；

l  Installation refer to the following:

Diagram2-2:  Equipment installation diagram(no appendix)

             Top-Fixed Figure                         Top-Fixed Figure

 description：

Ø  Fixed four nuts(with shrapnel, gaskets) on the reader；

Ø  L-type of direct regulator(use to adjust the direction from top to bottom maily)；

Ø  Two nuts (with shrapnel, gaskets) which fixed on the L-type of direct regulator；

Ø  Hold bar splint(configure by customers)；

Ø  U-type wire gong (with shrapnel, gaskets) (configure by customers)；

The main functions are as follows：

Ø  Equipment operation status indicator (indicator light, buzzer)；

Ø  Read the active read-only electronic tags correctly；

Ø  The read tag is saved into the buffer；

Ø  After reading the tag, the user can be informed by the indicator light and buzzer；

Ø  After reading the tag, it can be transmitted to the upper computer through RS232, RS485, WG26,WIFI(Optional),TCP/IP(Optional),GPRS(Optional)；

Ø  Communication mode has active transmission and passive transmission；

Ø  The RS232 communication rate can be set；

Ø  The distance to read the tag can be set (0-31 files)；

Ø  The interval time between reading the same tag can be set；

Ø  The interval time of active tag uploads can be set；

Ø  External trigger reads tag information；

Ø  Able to read equipment factory information；

2.parameter of  performance

Ø  Working temperature: -25℃ ~70℃；

Ø  Storage temperature: -40℃~85℃；

Ø  Working humidity: <95%；

Ø  Dimension: 320mm×200mm×100mm ；

Ø  Weight : 2.5kg；

Ø  Working voltage: DC 7.5－12V,provided by the power adapter；

Ø  Working current: less than200mA；

Ø  Frequency range:  2400－2500MHz；

Ø  Gain:  16dBi；

Ø  Lobe width of the horizontal：30°；

Ø  Lobe width of the vertical :25°；

Ø  Ratio :≥25dB；

Ø  Voltage standing wave ratio: ≤1.5；

Ø  Polarization: linear；

Ø  Work  frequency:2400－2500MHz；

Ø  Transmit  frequency:  single carrier；

Ø  Power of transmit carrier:<=0dBm；

Ø  Communication interface: RS232, RS485, WG26,WIFI(Optional),TCP/IP(Optional),GPRS(Optional)；

Ø  The communicate rate of RS232 ,which can be set （9600、14400、19200、28800、38400、57600（suggest use）、115200）；

Ø  The communicate rate of RS485, which can be set（9600、14400、19200、28800、38400、57600（suggest use）、115200）；

Ø  Communication protocol : send information again when error.

Ø  Identification of multiple tags；

Ø  Reading distance: 0-150m.

Ø  The device has an internal buffer capacity of 1000 tags；

Ø  Provide demo software, API functions, etc；

Ø  Register memory: send real-time；

Ø  Reading tag-type: communication protocol BSJ601；

Ø  Accuracy of identification: up to 99.999999%
