PVC Coated Barb Wire
Barbed wire is a barrier wire made by twisting a barbed wire around a main wire (strand) through a variety of weaving techniques.
There are three kinds of twisting methods for barbed wire: regular twisted barb wire, reverse twisted barb wire, twisting positive and negative.
Screwing method: It is to twist two iron wires or multiple wires into double wire ropes and then twist the ropes around the double wires.
Anti-twisting method: Firstly, the thorn wire is wound on the main wire (that is, a single wire), and then a wire is added and twisted into a double-stranded thorn wire.
Positive and negative twisting methods: It is the twisting of the direction in which the direction of the ground main wire of thorns is reversed. The wires are not twisted in one direction.
barb wire manufacturer:Xin Hui Metal Products Co., Ltd.
Strand and Barb in B.W.G. |
Barbs Spacing 3" |
Barbs Spacing 4" |
Barbs Spacing 5" |
Barbs Spacing 6" |
12x12 |
6.0617 |
6.759 |
7.27 |
7.6376 |
12x14 |
7.3335 |
7.9051 |
8.3015 |
8.5741 |
12-1/2x12-1/2 |
6.9223 |
7.719 |
8.3022 |
8.7221 |
12-1/2x14 |
8.1096 |
8.814 |
9.2242 |
9.562 |
13x13 |
7.9808 |
8.899 |
9.5721 |
10.0553 |
13x14 |
8.8448 |
9.6899 |
10.2923 |
10.7146 |
13-1/2x14 |
9.6079 |
10.6134 |
11.4705 |
11.8553 |
14x14 |
10.4569 |
11.659 |
12.5423 |
13.1752 |
14-1/2x14-1/2 |
11.9875 |
13.3671 |
14.3781 |
15.1034 |
15x15 |
13.8927 |
15.4942 |
16.6666 |
17.507 |
15-1/2x15-1/2 |
15.3491 |
17.1144 |
18.406 |
19.3386 |
Wire gauge |
packing 10kgs/coil |
1*20'FCL Quantity |
16GA*16GA |
160M/coil |
15TONS |
16GA*14GA |
125M/coil |
16TONS |
14GA*14GA |
100M/coil |
17TONS |
14GA*12GA |
80M/coil |
18TONS |
12GA*12GA |
65M/coil |
19TONS |
Wire gauge |
packing 10kgs/coil |
1*20'FCL Quantity |
16GA*16GA |
240M/coil |
15TONS |
16GA*14GA |
180M/coil |
16TONS |
14GA*14GA |
150M/coil |
17TONS |
14GA*12GA |
120M/coil |
18TONS |
12GA*12GA |
100M/coil |
19TONS |
Wire gauge |
packing 10kgs/coil |
1*20'FCL Quantity |
16GA*16GA |
400M/coil |
16TONS |
16GA*14GA |
300M/coil |
17TONS |
14GA*14GA |
250M/coil |
18TONS |
14GA*12GA |
200M/coil |
19TONS |
12GA*12GA |
160M/coil |
20TONS |
