Brief Description
Seamlessly combined laser diffraction and automated imaging into one system, Bettersizer S3 Plus can not only achieve a wide test range, but also provide reliable particle size distribution and particle shape information simultaneously. The excellent performance and intelligent operation mode make Bettersizer S3 Plus the best choice for research in need of particle size and shape characterization.
Features
- Smart Analysis of Particle Size and Particle Shape
- Mie Scattering Theory
- 96 Photodetectors
- Ultrasonic Wet Dispersion
- SOP Automatic Testing
- Dual Lenses Optical System
- Automatic Centering Function
- Automatic Circulation and Dispersion
- Combination of Laser Diffraction and Automated Imaging into One System
- Refractive Index Measurement for Unknown Powder Material
- Accuracy Calibration Function
- Automatic Water Intake and drainage
- Real-time Test Result Monitor
- Automatic Water Level Monitor
- Dew Point Temperature Monitor
- Anti-corrosive Pump Design
- Multi-language Software System
- Test Report Conversion
Parameters
-Model: Bettersizer S3 Plus
-Measurement Range: 0.01-3500 µm
-Sampling Method: Ultrasonic Wet Dispersion Built-in Automatic Circulation and Automatic Dispersion Sampling System
-Repeatability Error: ≤0.5%
-Accuracy Error: ≤0.5%
-Dual Peak Resolution: ≥1.65
-Measuring Principle: Mie Scattering Theory
-Measuring Way: SOP (Standard Operation Program)
-Fastest Measuring Speed: ≤10 s
-Laser Light Source: Solid State Laser
-Optical Systems: Dual lenses & Oblique Incidence Opticlal System, Automatic Centering , Automatic Testing
-Dew Point Temperature Testing: yes, the instrument has this function.
-Detection Angle Range: 0.02-165°
-Refravtive Index Measuring Range: 1.4-3.6
-Operating System: Win XP / Win 7/ Win 8/ Win 10
-Connection Port: USB 2.0 or USB 3.0
-Photodetector Quantity: 96 pcs
-Ultrasonic Disperser Power: 50 W
-Circulation Pool Volume: 600 ml
-Circulating Flowrate: 3000 - 8000 ml/min
-Voltage: AC 220 V , 50/60 Hz
-Image Analysis Range: 2-3500 µm
-High Speed CCD: 120 frm/s
-Magnification: 20-100 times
-Image Recognition Speed: 10000 particles/min
-Analytical Items: particle size, particle shape, particle size distribution, largest particle size, aspect ratio, circularity,etc.
-Dimension, Weight: 820 mm x 610 mm x 290mm , 48 kg
Packing
1. Use thickened cartons;
2. Thick foam board and buffer air bags are used to protect the instrument.
3. Use wooden cases made by the plywood outside the carton to further protect the instruments;
4. After the product is packed, we will carry out the package drop test to further ensure the safety of the instrument for long distance transportation.
Our Service:
Within One Year Warranty:
1.Free spare parts.
2.Send engineer to maintain (User pay the round-trip tickets).
3.Send back to maintain (Both sides share the half freight).
Out of Warranty:
1. If there is any breakdown resulting from misuse or out of warranty, the two sides should negotiate for the site & method of maintenance. Buyer is supposed to pay the expense.
2.Consumable items are not guaranteed.
