12.5kg Cylinder Reference |
Tech Data |
Unit |
Quantity (PC/40HQ) |
| 1062 | ||||
Customer Item No |
15 | kg | ||
Filling Medium |
|
|||
Standards |
ISO4706/EN1442 |
|||
Material |
HP295 | |||
Water Capacity |
35.5 | L | ||
Cylinder Body |
Outside Diameter(D) |
314 | mm | |
Nominal Thickness(T) |
3.0 | mm | ||
Body Height(BH) |
528 | mm | ||
| Body+Footring+ Guard | Total Height(TH) | 680 | mm | |
Valve Configuration |
Customized | |||
| Coating | Spray Plastics | |||
Color |
Customized | |||
Working Pressure |
2.1 | MPA | ||
Test Pressure |
3.2 | MPA |
The prodution flow as:
Material inspection→DISC cutting and deep drawing→Trimming and Joggling→Circumferential welding→Weld the collar and footring→Weld the valve boss→ Heat treatment(under temperature 820-930 degree) →Hydro-staticShot blasting→Leakage test→Valve install→Powder painting
More information
1.Our types Range as belows: 3kgs,5kgs.6kgs,9kgs,10kgs,11kgs,12.5kgs,15kgs ,19kgs,20kgs,25kgs,35kgs,45kgs,48kgs,50kgs and etc.
2.Color based on your requirment.
3.Logo could be stamped in the shroud or painted in the cylinder body.
4.Valves are available .We could also have kinds of burners for your choose.
