Elevated Telescopic 12m Camera Mast Pole

FOB Price

US$ 900 - 1,500 / Set

1 Set(Min. Order)

Port China main ports
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TALENTS 12m camera mast pole		Place of Origin	Tianjin, China
Model Number	TAL-M12-2.2-10

Product Description

Detailed Images

elevated telescopic 12m camera mast pole

Product Description

elevated telescopic 12m camera mast pole

technical data
main spec.	Closed length:2.2m (Bottom base included) Extended length: 12m (Bottom base included) Max loading:10kg Temperature: working temp:-50--+60 deg C Storage Temp:-55--+70 deg C
main pole in sections	Section No. OD Thickness 1# 30mm 2.0mm 2#: 40mm 2.0mm 3#: 50mm 2.0mm 4#: 60mm 2.0mm 5#: 70mm 2.0mm 6#: 80mm 2.0mm 7#: 90mm 2.0mm
Bottom base	diameter: 180mm Thickness: 12mm
Accessories	Pulling cord box with handle bars------------------3 units Ground anchor------------------------------------------3 pieces Handle lifting bar---------------------------------------2 pieces 304 stainless steel stakes-------------------------------6 pieces Tripod -----------------------------------------------------1 piece Top plate---------------------------------------------------1 piece
Material	Main Pole: aluminum alloy Bottom base and accessories(except the stakes): iron steel Pulling cord: stainless steel wire(OD:2mm)
Color	the whole unit will be in army green when closed, but when extended, the main pole will be in origin color of aluminum alloy only with top 4cm of each pole section in army green color.Technology: painting

accessories

Pulling cord box with handle bars------------------3 units
Ground anchor------------------------------------------3 pieces
Handle lifting bar---------------------------------------2 pieces
304 stainless steel stakes-------------------------------6 pieces
Tripod -----------------------------------------------------1 piece
Top plate---------------------------------------------------1 piece

Packing & Delivery

elevated telescopic 12m camera mast pole

package
carton packed	normal package is carton for the extended height less than 9m, weight less than 70kg mast, also can be plywood case at customers request
plywood packed	normal package is plywood case for extended height more than 10m, weight more than 70kg mast

Workshop

Our Service

we supply telescopic mast up to 35m,usually used as antenna mast,communication tower,light support,camera mast and so on,custom-made payload to 400kg,customized length,retracted,payload etc. accepted.

catalog of some common grade manual mast as follows-

extended height (m)	No. of section	retracted height (m)	outer tube range (mm)	self weight (kg)
4	3	1.6	60-80	14
5	4	1.65	50-80	17
6	5	1.7	50-90	21
8	6	1.8	40-90	24
10	7	1.95	30-90	26
12	7	2.2	30-90	28
15	8	2.45	30-105	33
18	9	2.7	30-130	47
20	9	2.95	30-130	55
22	9	3.15	30-130	58
25	10	3.4	30-150	72
30	10	3.85	30-150	84

why choose our masts

1.all masts include 1 year limited warranty

2.this type masts are extendable manually, no pumps, no complex extension devices,

no power sources required.

pletely maintenance-free

4.deliveried ready to use

5.we ship worldwide

Welcome to contact

contact person: Ms.Grace Wang

Talents Enterprise Company Limited

T: 86 22 28376666 | F: 86 22 28376667 |
Skype:talents106

whatsapp:0086 18222428293

wechat: 1093812653

if you get interested in our telescopic mast, please contact us at any time for catalog and videos
