Chief Characteristic:
Axial wire leads, glazed, small size. Power load, high precision resistance, we can provide users with 1% /2% tolerance range of products. It is suitable for printed circuit board mounting. They are widely used in DC or low frequency AC circuits.
Contour Drawing
Chief Technology Parameters & Contour Dimensions
|
Power (w)
|
Resistance Range(ohm)
|
Resistance Tolerance(%)
|
Limit Voltage(v)
|
Temperature Coefficient (PPM)
|
Contour Dimension (mm) |
||
L max |
ΦD max |
Φd |
|||||
2.5 |
1-1.0k |
3 |
100 |
R≥10Ω TCR ≤± 200 5ΩR10Ω TCR ≤± 400 R≤5Ω
|
12.7 |
5.6 |
0.8 |
3.0 |
1-1.0k |
3 |
120 |
14.0 |
7.0 |
0.8 |
|
4.3 |
1-3.6k |
3 |
160 |
23.0 |
7.0 |
0.8 |
|
6.0 |
1-6.8k |
5 |
200 |
22.2 |
8.0 |
0.8 |
|
6.5 |
1-8.2k |
5 |
240 |
23.7 |
8.0 |
0.8 |
|
8.0 |
1-15k |
5 |
400 |
34.0 |
8.0 |
1.0 |
|
9.0 |
1-20k |
10 |
500 |
38.1 |
8.0 |
0.8 |
|
11.0 |
1-30k |
10 |
750 |
46.8 |
10.8 |
1.0 |
|
12.0 |
1-30k |
10 |
750 |
53.5 |
8.0 |
0.8 |
|
Note: Go beyond the afore cited scope, we can provide the products according to the user's requirements.
Xianyang Qinhua Special Electronic Components Co., Ltd established in June 23, 2000, which located in Xianyang, Shaanxi Province.we are one of the top 10 manufacturers for all kinds of Resistor in China.
Our products are widely used in the domestic electrical and electronic environmental protection, power electronics, electrical and mechanical engineering, trade, wiring harness, electronic components industry support, large-scale security quarantine inspection and accelerator and isotope industry, medical equipment, High-voltage soft start system, automatic control industrial control, textile equipment, radio transmitter (dummy load), medical equipment , machine tool industry, electrical drive, railway signal electronic control, electronic systems engineering, switching technology, Chinese Academy of Sciences System University. we started oversea business since 2012, the products are exported to the United States,UK,South Korea, Austria, the United Arab Emirates, Denmark, Netherlands, South Korea, Brazil, Chile and more than 50 countries.
A: We are factory.
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
A: 100% in advance before shippment.
