Drying plastic granules blender
XC-GH series color mixer machine
1.Temperature and timer control in one unit,convenient for parameters setting;
2.Well-designed structure,easy to operate.
3.Stainless steel construction,easy to clean;
4.Doyble layer protection to maintain temperature.
5.Mixing in airtight chamber,magnetic separation process(optional)
6.Automatic alarm for overload protection.
Working principle:
The dry color mixer series operated in high-speed rotation of mixing,to cause plastic particle churn and collide,thus raise temperature by friction.Color materials mixed while moisture evaporated from exhaust pipe.
Product Specification:
Model | Power(Hp) | Capacity(kg) | Voltage(V) | Dimension(mm) | Rotating speed(r/min) | Net weight(kg) |
XC-HG50KG | 10 | 50 | 380/3φ | 1170*830*1350 | 480 | 230 |
| Model | Power(Hp) | Capacity(kg) | Voltage(V) | Dimension(cm) | Rotating speed(r/min) | Net weight(kg) |
| XC-GH25KG | 7.5 | 25 | 380/3φ | 100*69*124 | 480 | 200 |
| XC-GH50KG | 10 | 50 | 380/3φ | 117*83*135 | 480 | 230 |
| XC-GH100KG | 20 | 100 | 380/3φ | 134*98*152 | 480 | 270 |
| XC-GH200KG | 40 | 200 | 380/3φ | 170*130*170 | 480 | 700 |
![]() | ![]() | ![]() |
