Hydraulic Drilling Rig XY-150 Water Well Drilling Machine/high Speed 100meters Drilling Equipment From HuaxiaMaster for Sale Good Price
US$ 4900 - 5300
/ Set
1 Set(Min. Order)
- Qingdao
- T/T L/C
You May Like
-
Supply Hydraulic Water Borehole Drilling Machine XY-180/ Well Equipment Core Drilling Rig for Sale High Efficiency
-
High Speed Water Well Drilling Rig XY-200 Core Drilling Rig//exploration Drill Machine With Good Price for Sale
-
Water Well Rig/hydraulic Core Drilling Rig /large Size Sample Machine XY-3 for Sale Multi Function for Price
-
Wheeled Hydraulic Core Drill Rig XYX-3 Hydraulic Water Well Machine//600m Water Well Drilling Equipment for Sale
-
Hot Sale Crawler Type Rock Drilling Rig XYD-3 /diesel Engine Water Well Drill Machine 600m Depth Easy Move for Sale
-
HuaxiaMaster Supply XYC-3 Vehicle-mounted Hydraulic Core Drilling Rig/civil Water Well Drilling Machine for Sale
Product Details
| Brand Name | HuaxiaMaster | Place of Origin | China | |
| Model Number | XY-150 | Type | Core Drilling Rig | |
| Certification | iso9001 | After-sales Service Provided | Overseas third-party support available | |
| Warranty | 6months | Weight | 600kg | |
| Dimension(L*W*H) | 2500*1000*1200 mm | Power Type | Diesel | |
| Usage | Other, water well engineering | Condition | New | |
| Power(W) | 11kw |
Product Description
XY-150 hydraulic core drilling rig
1. Applications of XY-150 hydraulic core drilling rig
· geological survey
· geophysical exploration
· road and high-rise building foundation exploration
· water wells
· blasting holes and other drilling projects
2. Parameters of XY-150 hydraulic core drilling rig
Drilling depth(m) | 150 |
Maximum opening diameter | 219 |
End hole caliber
| 73 |
Rod diameter | 42/50 |
Spindle speed (r/min) | 140/295/470/790/1010 |
Spindle stroke | 450 |
Hoisting capacity (kn) | 14 |
Steel wire diameter | 9.3 |
Maximum pressure (mpa) | 1.2 |
Working pressure (mpa)
| 0.7 |
Displacement | 150 |
Hydraulic pump pressure (mpa) | 1.2 |
Hydraulic pump rotation speed (r/min)
| 1800 |
Matched driving power (diesel engine and motor) | S1105 diesel engine and 11kw motor |
