CNC Muti-function Double-head Cutting Saw
LJDGN2BS-500X5000
Multi-function cutting saw for aluminum profile LJDN2BS-500X5000
1.Feature
1.1 The two saw head independent swing angle,adopt cylinder driving,set up three common angle that is -45° 90°+45°
1.2 Set up Manually position at arbitrary angle function within 45°~90°,the knob to the positioning position,make the pendulum angle cylinder pressure to be released in full,avoid plane positioning arbitrary angle position change.
1.3 When saw head swing to 45°,the front protection hood automatically to two saw head of intermediate mobile,which increase the reliability of safety production.
1.4 Large cutting range,cutting 160~220mm when 90°,cutting 160~155mm when 45°(Profile width less than 160mm,the corresponding height increase).
1.5 The right saw head follow-up material carrying frame length is 1800mm
2.Technical Parameter
2.1 Input power : 5.9kw
2.2 Power supply: 380V/50Hz
2.3 Air pressure: 0.6~0.8MPa
2.4 Motor rotary speed: 2800r/min
2.5 Saw blade specification: φ500xφ30x4.4
2.6 Cutting angle : 45°~90°~135°
2.7 Cutting length : 580~5000mm
2.8 Cutting width x height : 160 x 155mm
2.9 Overall dimension :7300 x 1300 x1500mm
3.0 Weight about :1800 kg
Parameter
Input Power |
5.9kw |
Power Supply |
380V/50Hz |
Working Pressure |
0.6-0.8 MPa |
Rpm |
2800r/min |
Size of Saw Blade |
φ500xφ30x4.4 |
Cutting Angle |
45°~90°~135° |
Cutting Length |
580~5000mm |
Cutting Width * Height |
160x155mm |
Dimension |
7300*1300*1500 |
Weight |
1800kg or so |
3.Picture of machine
4.Detailed
5.Our factory
6.Delivery
7.Our customer
8.Contact us
