Hot Sale Window and Door Making Machine Double head Cutting Saw for PVC Profile

Standard wood packaging

Hot Sale Window and Door Making Machine Double head Cutting Saw for PVC Profile

Features:

1. Suitable for cutting pvc profile, Aluminum profiles .

2.Adopts industry grade computer system, closed-loop controlled, high precision and quick shift for cutting size.

3.Adopt push-button operation screen, and with USB interface, it can realize the data interchange via by input external memorizer.

4. Optimized function: optimizing to cut according to the working list.

5. Tabulation cutting function: several kinds of profiles can be selected quickly.

6. Continuous feeding: auto feeding profile at 90 degree cutting.

7. Ultra-short cutting function: soft controls the cutting function can realize the short material. The min. cutting length is about 100~400mm

8. Angle automatic indexing:-45°,67.5° , 90°.

9. High precision linear guiding pair ensured steady and long-term processing accuracy.

10.Adopt imported air-hydraulic conversion device, so that ensure running stably;

11. Stability high precision machine body, the design of machine body conform to the aesthetic point and human body engineering principle.

12. Auto opening shield with rubber seal makes the operator more safety.

13. The middle profile supporter and movable carrier make the loading convenient. It's compact structure follows the operation custom in better way.

14. Pressure protection/alarm device: to realize the effective quality control should make the machine start and work in normal pressure which strictly conformed to the requirement so as to avoid quality problem and operational safety.

15. Equipped with phase sequence protection device, so as to protect the machine once shut off or misconnect the phase.

Technical Specifications
