Angle Cut 45 Degree Band Saw Machine For Aluminum Windw

Specification:
1. This machine is applicable for cutting aluminum and PVC profile
2. at the angles of -45°, +45°, 90°.
3. Its carbide cutters are directly fixed on motor shafts and can swing freely to meet processing demand, which give the machine high cutting speed and accuracy.
4. The two sawing units can cut profiles simultaneously and separately,the saw blade can swing to required angle.
Technical Parameter:
Made to order | |
motor power | 3kW(1.5kW*2) |
Spindle Rotary Speed | 2800 r/min |
Operation air pressure | 0.5~0.8MPa |
Air consumption | 200L/min |
Max.Cutting length | 3700mm |
Min.Cutting length | 220mm(double-head) |
Cutting width | 120mm |
Cutting height | 150mm |
Cutting angle | 22.5° 45°And 90° |
Cutter feeding speed | 0~3 m/min Stepless speed regulating |
Cutting profile surface plane | ≤0.10mm |
Cutting angle tolerance | Ra12.5 μm |
Saw blade specification | φ450mm×3.2mm×φ30mm Z=80 |
Dimension | 4500*1300*1450mm |
Weight | 1600kg |


We have excellent sales and after-sales team
2.Sample service:
Our engineer is available to travel abroad, help the installation, maintenance and training staff.
3. Customized service:
Free industrial information, free investment analysis for windows, doors, and curtain wall project, free layout design for window, and door and curtain wall product line.
4.After sales service:
One year guarantee
Free adjustment
Free training to operation and maintenance workers
Free industrial information
Free investment analysis for windows,doors and curtain wall project
Free layout design for windows,doors and curtain wall production lines
Provide follow-up service,regular maintenance and lifetime service for our machines sold
Provide quick supply of spare parts for window and curtain wall companies.
Provide technical support including pressure design and caculation for window and curtain wall companies
We support Trade Assurance on Alibaba, which is a free payment protection service for buyer regarding product quality and transaction security.

1) We can send you free components to you if your machines are in guarantee time.
2) We can send our engineers to repair your machines
3. what services can provide in your company ?
1) one year guarantee
2) free adjustment
3) free training to operation and maintenance workers.
4) free industrial information
5) free investment analysis for windows, doors and curtain wall project.
6) free layout design for windows,doors and curtain wall production lines.
7) provide follow-up service, regular maintenance and lifetime service for our machines sold.
8) provide technical support including pressure design and caculation for window and curtain wall companies.
9) provide quick supply of spare parts for window and curtain wall companies.
4. Quick detail of our company.
Company Name | JINAN DEGA MACHINE CO.,LTD. |
Year established | 2006 |
Address | No.389,TIANCHEN ROAD,JINAN CITY,250101 CHINA |
Business type | Manufacturer |
Product range | CNC Machining Centre, aluminum cutting machine, corner key cutting, end milling machine,punching machine,copy router, crimping machine, drilling and bending machine |
Product advantage | Using advanced solidworks design platform |
Management certificate | ISO9001,national patent |
Fair we attend | Shanghai and Beijing international windows show |
E-catalog | available |
MOQ | 1 set |
Payment terms | TT or L/C |
Shipping port | Qingdao port |
